Kohler KD83V16 User Manual

Maintenance Operation and Maintenance Manual
Daily or monthly maintenance activities
u Release and remove ratchet wrench.
w
The tensioning device is released
Fig. 54: Checking V-ribbed belt tension — Measurement area (left)
1 Sensor 3 Belt section
2 Light beam
u Check tension with adequate tool. The measured frequency value must be 165 Hz (Min149 Hz -
Max 182 Hz).
In case of air conditioning compressor installed, proceed in the same way.
Information
Mount the battery charging alternator cover in reverse sequence. (For more information see:
5.6.3 Removal of the battery charging alternator cover, page 95)
5.6.6 Replacing tensioning device — SL110
q The battery charging alternator cover is dismounted. (For more information see: 5.6.3 Removal
of the battery charging alternator cover, page 95) .
q The V-ribbed belt is removed. (For more information see: 5.6.5 Replacing V-ribbed belt — SL
109, page 97) .
98
© 2018 by Kohler Co. All rights reserved.
KD83V16 33521030601_0_1 EN_US
2018-07
