Operation and Maintenance Manual Transportation - Storage
Dimensions and weight
Designation Ref. SI-Value US-Value
Distance between engine lifting points Z2 1290 mm 50.78 inch
Distance between engine lifting points - right side X3 1300 mm 51.18 inch
From RFOB to lifting point - right side X2 594 mm 23.39 inch
Distance between engine lifting points — left side X4 1040 mm 40.94 inch
From RFOB to lifting point — left side X5 545 mm 21.45 inch
Axis to lifting point Y2 729 mm 28.70 inch
Maximal weight P 11300 kg 24912 lbs
Maximal angles of lifting devices — side view α1–α2 15°
Maximal angles of lifting devices — front view β1–β2 15°
Tab. 14: Dimensions and weight of engine - values
KD83V16 33521030601_0_1 EN_US
2018-07
