4
_07
22
MIN
MAX
B
B
A
4.1
4.2
EN
INFORMATION ABOUT USE
1. Loosen the oil filler cap A.
2. Add the type oil recommended (Tab. 2.1 and Tab. 2.2).
3. Before checking oil engine needs to be level.
4. Remove the oil dipstick B and check that the level is up to
but does not exceed the
MAX
.
5. If level is not at the MAX. level, add additional oil.
6. Re-tighten the cap A.
Important
• Do not use the engine with the oil level below the minimum.
4.4 Refuelling
Important
• Before proceeding with operation, read Par. 3.2.2.
Danger
• Fill the engine off.
• The only approved fuels are those listed in Tab. 2.3.
• In those countries where diesel has a high sulphur content, its is advisable to lubricate the engine with a high alkaline oil or
alternatively to replace the lubricating oil recommended by KOHLER more frequently.
• To avoid explosions or fire outbreaks, do not smoke or use open flames during the operations.
• Fuel vapours are highly toxic.Only carry out the operations outdoors or in a well ventilated place.
• Keep your face well away from the fuel fill to prevent harmful vapours from being inhaled.
• Dispose of fuel in the correct way and do not litter as it is highly polluting.
• When refuelling, it is advisable to use a funnel to prevent fuel from spilling out.The fuel should also be filtered to prevent dust
or dirt from entering the tank.
• Do not overfill the fuel tank. Leave room for the fuel to expand.
NOTE: At the first fuelling or if the tank was empty filling the fuel system (Par. 6.3 point 8).
4.5 Oil filling
Important
• For safety precautions see Par. 2.4.
• Before proceeding with operation, read Par. 3.2.2.
ED0053030050
