5
_07
26
B
B
A
A
A
C
A
5.3
5.4
EN
INFORMATION ABOUT MAINTENANCE
5.5 Check of the radiator heat-exchanger surface
NOTE: Component not necessarily supplied by KOHLER.
5.7 Check coolant level
NOTE: Component not supplied by KOHLER.
Refer to the technical documentation of the vehicle.
Danger
• For safety precautions see Cap. 3.
5.6 Rubber hoses check
The check is carried out by exerting a slight deflection or
bending along the pipe and near the hose clamps.
Components must be replaced if they have clear signs of
cracks, tears, cuts, leaks and do not retain a certain degree
of elasticity.
Important
• Before proceeding with operation, read Par. 3.2.2.
• If hoses are damaged contact an authorized KOHLER
workshop.
• For other pipes not illustrated refer to the technical
documentation of the vehicle.
1. Check that the:
- Fuel system hoses A are intact.
-
- Cooling circuit hoses B.
-
- Vent system pipes C.
ED0053030050
