5
_07
24
5.1
5.2
EN
INFORMATION ABOUT MAINTENANCE
CLEANING AND CHECKING
OPERATION DESCRIPTION
PERIOD (HOURS)
PAR.
10 250 500 1000 1500 5000
Engine oil level
5.3
Coolant level /
Check of the radiator heat-exchanger surface
(2)
Components not supplied by KOHLER.
Refer to the technical documentation of the
vehicle
5.7
5.5
Cartridge dry-type air filter
(2)
5.4
Radiator heat-exchange surface and Intercooler
(2)
5.5
Alternator belt tension
(5) (8)
5.8
Rubber hose (intake air / coolant)
5.6
Fuel hose
--
Starter Motor
(6)
--
Alternator
(6)
--
5.2 Periodic maintenance
The intervals of preventive maintenance in Tab. 5.1, Tab. 5.2 and Tab. 5.3 refer to the engine operating under normal operating
conditions with fuel and oil meeting the recommended specifications.
REPLACEMENT
OPERATION DESCRIPTION
PERIOD (HOURS)
PAR.
10 250 500 1000 1500 5000
Fuel prefilter Type A
(1)
Fuel prefilter Type B
(1) (6)
--
Fuel filter cartridge
(1)
6.3
Coolant
(4) (6)
--
Intake manifold hose (air filter - intake manifold)
(6) (7)
--
Coolant hoses
(6) (7)
--
Fuel line hose
(6) (7)
--
Alternator belt
Poly-V belt heavy environmental condition
(6)
--
Poly-V in condizioni normale
(6)
Dry air cleaner external cartridge
(2)
After 6 checks with cleaning 6.4
• This chapter shows all operations described in the Tab.
5.1 and Tab. 5.2 if you have the skills appropriate may be
directly carried out by the user.
• Periodic inspection and maintenance operations must
be carried out as indicated in this manual and are the
responsability of the user.
• Failure to comply with these service and maintenance
intervals increases the risk of technical damage to the
engine. Any non compliance makes the warranty become
null and void.
• In order to prevent personal and property damage read
carefully the instructions listed below before proceeding
with any operation of the engine.
5.1 Useful information about maintenance
Important
• Before proceeding with operation, read Par. 3.2.2.
Warning
• Inspections must be made when the engine is off and cold.
• Place engine on level surface to ensure accurate
measurement of oil level.
• Before starting, to avoid spillages of oil make sure that:
- the oil dipstick is inserted correctly;
- also check that:
oil drain plug and; oil filler cap are tightened firmly.
ED0053030050
