5
_07
25
MIN
MAX
B B
A
5.3
5.1
5.2
EN
INFORMATION ABOUT MAINTENANCE
5.4 Air filter check
NOTE: Component not supplied by KOHLER.
Refer to the technical documentation of the vehicle.
5.3 Oil level check
1. Loosen the oil filler cap A.
Remove the oil dipstick B and check that the level is up
to MAX.
2. Pour in recommended oil until reaching the MAX level
mark.
3. Reinstall the oil dipstick B completely.
4. Re-tighten the cap A (Fig. 5.2).
Important
• Do not use the engine with the oil level below the minimum.
1. In case of low use: 12 months.
2. The period of time that must elapse before checking
the filter element depends on the environment in which
the engine operates. The air filter must be cleaned and
replaced more frequently under very dusty conditions.
3. In case of low use: 36 months.
4. In case of low use: 24 months.
5. Not Poly-V type.
6. The replacement must be carried out by authorized
KOHLER workshops.
7. The replacement interval is only an indication, it strongly
depends from environmental condition and hose status
detected during regular visual inspection.
8. The first check must be done after 10 hours.
ENGINE OIL AND OIL FILTER CARTRIDGE REPLACEMENT
ENGINE VERSION
PERIOD (HOURS)
PAR.
250 500
TCR
(1)
6.1
6.2
TCR/D TIERIII
(1)
ED0053030050
