TP-6928 1/1414 Section 1 System Information and Installation
1.8 Controller Firmware Download
and Installation
It may be necessary to update the firmware on your
generator set controller. See Figure 1-6 for the firmware
version r equired for your device. Refer to the generator
set documentation for instructions to find the version
number installed on your controller.
Note: Controller firmware can be updated by a Kohler
authorized distributor or dealer using a personal
computer and Kohlerr SiteTecht software. The
Kohler OnCuer Plus application cannot be used
to update controller firmware.
Firmware V ersion Numbers
Software and firmware version numbers consist of three
parts separated by periods (or dots) as follows:
[Major version number].[Minor version number].[Build number]
For example, if the version number is 2.3.17, the major
version number is 2, the minor version number is 3 and
the build number is 17. The build number is typically not
shown on the controller display, but is included in the
firmware file name.
Preceding zeros may be dropped from version numbers
for software and firmware. For example, firmware
version 2.3 is the same as version 2.03. However,
version 2.1 (two point one) is not the same as 2.10 (two
point ten).
Model Controller Firmware Version Number * Firmware File Name [
6VSG VSC 1.00 VSC_#_#_#.bin
6VSG w/comm. kit VSC 1.02 VSC_#_#_#.bin
14/20RES RDC 3.00 RDC_#_#_#.bin
14/20RESL DC 3.00 RDC_#_#_#.bin
14/20RESA RDC2 4.03 RDC2_#_#_#.bin
14/20RESA with APM RDC2 105.04 RDC2_###_#_#.bin
14/20RESAL DC2 4.03 RDC2_#_#_#.bin
38RCL RDC2 4.10 RDC2_#_#_#.bin
48RCL RDC2 4.03 RDC2_#_#_#.bin
* This firmware version number or higher is required.
[ #_#_# in the file name is the firmware version number.
Figure 1-6 Controller Firmware Version Numbers and File Names
