Kold-Draft GB564LC - Page 58

new 60 Series Service Manual.rev. 06.01.16.docx - 53 –
1-Water Valve
5-Condenser (Liquid Cooled)
Left Side
Liquid Cooled
6-Condenser (Air Cooled)
2-Defrost Valve Coil
3-Defrost Valve Body
4-Liquid Regulator Valve
Defrost Valve Coil
GT564
102101201
No.
Description
Model(s)
Part No.
1
Water Valve-115V
Before S/N 607945
GT561
102138301
Water Valve-115V
After S/N 607945
GT561
102141201
Water Valve-230V
Before S/N 607945
GT564
102138401
Water Valve-230V
After S/N 607945
GT564
102141101
2
Defrost Valve Coil
GT561
102101101
Defrost Valve Coil
GT564
102101201
3
Defrost Valve Body
GT56x
102101001
4
Liquid Regulator Valve
GT56xL
GAR00701D
5
Condenser-Liquid Cooled
GT56xL
102102101
6
Condenser-Air Cooled
GT56xA
102101803
GT56x Parts -Right Side
Water valve in same location on “A” and “L” models.
