Koldwave 2AK1411M - Parts List

29
KOLDWAVE 2AK (AIRMASTER)
KOLDWAVE AIRMASTER 2AK
SERVICE AND REPLACEMENT PARTS LIST
PART # DESCRIPTION 2AK10 2AK14
STRAINERS
010-A-050 STRAINER #750011-6 X X
ASSEMBLIES, STRAINER AND CAP TUBE
SA010-A-099 STRAINER CAP TUBE ASSEMBLY X
SA010-A-098 STRAINER CAP TUBE ASSEMBLY X
BLOWERS AND BLOWER ACCESSORIES
013-A-151 BLOWER WHEEL S52-34/18-1/2 CW X X
013-A-152 BLOWER WHEEL S52-33/18-1/2 CCW X X
013-C-154 BLOWER HOUSING #450C EVAPORATOR X X
013-C-155 BLOWER ASSEMBLY 90-7T CONDENSER X X
013-B-153 INLET RING #517 X X
COMPRESSORS
020-A-233 COMPRESSOR RK124AT X
020-A-261 COMPRESSOR 2P17S3R1268 X
ELECTRICAL COMPONENTS
025-A-645 SERVICE CORD 16/3 15 AMP 115V. X
025-A-624 SERVICE CORD 14/3 20 AMP 115V. X
025-A-616 RED INDICATOR LIGHT 3LF4LRN1-20L 115V. X X
025-A-617 BLUE INDICATOR LIGH 3LF4LRN1-30L 115V. X X
025-A-608 ROCKER SWITCH TIGM721 COOL/OFF/FAN X X
025-A-609 ROCKER SWITCH TIGB51 LO/HI X X
SA025-A-618A MICROSWITCH BA-2RV-A2 X X
FILTER/AIR
030-A-041 EVAPORATOR FILTER 15-7/8 X 18 X X
030-A-055 CONDENSER FILTER 16-1/2 X 19-3/8 X X
EVAPORATORS
031-A-215 EVAPORATOR COIL #61488 X
031-A-208 EVAPORATOR COIL #61259 X
CONDENSERS
031-A-216 CONDENSER COIL #61489 X X
MOTORS/BLOWERS
050-D-146 EVAPORATOR 7189-6316 X X
050-D-145 CONDENSER 7121-2186 X X
CAPACITORS/MOTORS
017-A-010 RUN CAPACITOR 25 MFD @ 370V. X X
017-A-099 RUN CAPACITOR 5 MFD @ 370V. X X
CASTERS
021-A-044 CASTERS 121-2.5 (4 BOLT MOUNT) X X
CONTROLS
066-A-090 HIGH PRESSURE SWITCH G23-5304-37 X X
066-A-104 DEFROST CONTROL A30-2316-00 X X
066-A-098 THERMOSTAT C12-2027 X X
CAPILLARY TUBES
067-A-285 CAPILLARY TUBE .049 X 56" 2 3
DISCHARGE GRILLES
SA038-D-013 GRILLE ASSEMBLY W/SPRING CLIP X X
076-A-921 SPRING CLIP XX
KNOBS AND HANDLES
041-A-015 CONTROL KNOB G-11-ML X X
042-A-016 DOOR PULL 14208-3740 X X
ASSEMBLIES/CABINET
076-C-2214 LEFT SIDE PANEL X X
076-C-2216 RIGHT SIDE PANEL X X
076-D-2210 FRONT PANEL W/SILK-SCREEN X X
076-D-2209 TOP PANEL XX
076-C-2224 REAR PANEL XX
076-C-2217 ACCESS DOOR X X
