I.5.1 04S functional units
The following circuit sections are built onto a single Eurocard, 199x100x12TE with
SMD-technology:
n
3-phase power supply with smoothing capacitors (-P-)
n
single phase supply (any phase with the rated voltage, possibly with extra
smoothing capacitance) is possible
n
fuses for DC-link, ballast circuit and auxiliary power supply
n
ballast circuit with -w- characteristic
n
4-quadrant output stage (V-MOS transistors)
n
auxiliary supply, optionally (solder links) supply from the DC-link
or an external 24 V DC source
n
2 differential setpoint inputs
n
input for DC tacho
n
Enable input
n
limit-switch inputs positive / negative
n
integral-off input for driving up to a fixed stop
n
I
2
t monitoring for actual current value
n
PI current and speed controller
n
trimmer potentiometer and fixed components for all important settings
n
solder links for changing to IxR compensation for optional operation with
tachometer or armature voltage control
n
24 V logic with electrically isolated optocouplers for the control signals, PLC-compatible
n
system ready (BTB) relay with floating contact
n
display LEDs for operational readiness / fault
n
±15 V auxiliary voltage outputs, ±20 mA
Prot
ective and monitoring functions
n
protected from short-circuit / earth short on the motor connection terminals
n
monitoring of the operating voltages
n
temperature monitoring of the output stage
n
fuse-protection of: ballast circuit, DC-link, auxiliary supply
n
I
2
t monitoring of the amplifier and motor
n
overvoltage protection
Page I - 4 General Chapter I
Series 04S 12.99 Kollmorgen
