I.6 Technical data
I.6.1 04S technical data
Rated data units 04S-M60/8-PB 04S-M60/12-PB
Rated supply voltage V~ 3x43 3x43
Rated installed load kVA 0.5 0.75
Rate DC-link voltage V= 60 60
Minimum DC-link voltage V= 18 18
Rated output current A 8 12
Peak output current A 20 20
Switch-on threshold of ballast circuit V 85 85
Switch-off threshold of ballast circuit V 75 75
Pulse power of ballast circuit W 1000 1000
Continuous power of ballast circuit W 35 35
Overvoltage switch-off threshold V 100 100
Form factor of the output current (under rated conditions
with 0.5mH min. load inductance of the motor )
— 1.01 1.01
Bandwidth of the subordinate current controller kHz 1 1
Output stage clock frequency kHz 8.5 8.5
Residual voltage drop at rated current V 4 4
Quiescent dissipation, output stage disabled W 7 7
Dissipation at rated current ( incl. power supply losses,
without ballast dissipation )
W40 80
Auxiliary voltage outputs V ±15 ±15
mA 20 20
Inputs
Setpoint 1, fixed setting V ±10 ±10
Setpoint 2, adjustable 0 — 100% V ±10 ±10
Max. common mode voltage (both setpoint inputs) V ±10 ±10
Input resistance (both setpoint inputs)
kW
20 20
Max. input drift (both setpoint inputs) µV/K ±15 ±15
Tacho input, adjustable V ±8..75 ±8..75
Logic inputs V 24 24
mA 8 8
Connections
Controller: control signals and power signals DIN 41612 - M24 + 7
Backplane: control signals F03SMB Combicon 5.08 16-pin
R03SMB Combicon 5.08 2x8-pin
Power leads Studs M6
Mechanical
Weight kg 0.5
Dimensions mm
199x100x45
(single Eurocard,12 TE) compatible
with 220mm insertion depth
Chapter I General Page I - 5
Kollmorgen 12.99 Series 04S
