I.6.2 Permissible ambient conditions, ventilation, mounting position
Transport temperature/humidity see Chapter VI.1
Storage temperature/
humidity/duration
see Chapter VI.1
Supply voltage tolerances
power stage
aux. supply (Option -24V-)
3x43V AC ±10%
min. 20V DC / max. 30V DC referred to -GND
Ambient temperature T
AMB.
in operation
0 ... +45°C under rated conditions
+45 ... +55°C with derating 2.5%/°C (forced convection)
Humidity in operation 5 ... 85 % rel. humidity, no condensation
Site altitude
up to 1000m a.m.s.l. without restriction
1000 ... 2500m a.m.s.l. with derating 1.5%/100m
Pollution level pollution level 2 according to EN60204/EN50178
Protection class IP 00
Mounting location / position in closed switchgear cabinet / normally vertical
Ventilation cont. current < 8A
and T
AMB.
< 45°C
cont. current ³ 8A
or T
AMB.
> 45°C
self-ventilating with natural convection (we always recommend
forced convection at higher loads or in narrow spaces).
forced convection
ensure that the incoming air is dust-free and that there is an
adequate supply of cooling air to the cabinet.
I.6.3 Cable cross-sections
In accordance with EN 60204 and taking account of the operating conditions in multi-axis
systems, we recommend the following cross-sections :
Controller type
Dimension
04S-M60/8-PB
[mm²]
04S-M60/12-PB
[mm²]
AC connection 4i x 1.5 4i x 2.5
DC-link 2 x 1.5 2 x 2.5
Motor leads 3i x 1.5 3i x 2.5
Tacho 2 x 0.25 (twisted, shielded)
Setpoints 2 x 0.25 (twisted, shielded)
Control signals, BTB 0.5
+24 V / GND 1.0 (Option -24V-)
I.6.4 Fusing
Rated data Type 04S-M60/8-PB 04S-M60/12-PB
Fuse S1 (DC-link, 5x20mm) AT 10 12.5
Fuse S2 (auxiliary supply, Microfuse) AM 1 1
Fuse S3 (ballast, 5x20mm) AT 2.5 2.5
Page I - 6 General Chapter I
Series 04S 12.99 Kollmorgen
