I.5 04S equipment description
Design
Plug-in 19”-rack module, connection through module back-panels or mating connector FH24+7
Size
Unit Format Height units (HE) Width units (TE)
04S
Eurocard,
220mm insertion depth
3HE (100mm) 12TE (approx. 61mm)
Options
-24V- supply for the electronics from an external 24V power supply
-IxR- speed control without a tachometer
--- front panel
Mains power supply
— 3-phase via isolating transformer
— 1-phase via isolating transformer
— DC-supply (battery)
Function
The 04S transistor controller is equipped for driving DC motors in 4-quadrant operation with
tachometer feedback. The power section is implemented as a pulse-width modulated transistor
stage with V-MOS transistors.
Variants
04S-M60-8-PB : rated output current 8A, with “soft” ballast characteristic
04S-M60-12-PB : rated output current 12A, with “soft” ballast characteristic
Accessories
Isolating transformers : series 3TxxK-60 (see Chapter IV.1)
-FH24+7- : mating connector DIN41612-M24+7 with solder contacts
F back-panels : instrument connections are accessible from the back,
via plug terminals for the control signals and studs/flat pin
connectors for the power connections
R back-panels : instrument connections are accessible from the front,
plug terminals for the control signals and studs/flat pin
connectors for the power connections
19”-rack modules : 19” base units in various widths, with F or R back-panels
Chapter I General Page I - 3
Kollmorgen 12.99 Series 04S
The following transistor controllers must be operated with forced convection:
— all 04S transistor controllers with rated output currents > 8A
— all 04S transistor controllers at ambient temperatures > 45°C
