I General
I.1 Introduction
This manual explains the installation, commissioning, adjustment and adaptation of the 04S
transistor controller.
The manual is divided into 6 chapters :
Chapter 1: General Information
Chapter 2: Notes on Installation and Commissioning
Chapter 3: Functions and Options
Chapter 4: Peripheral equipment
Chapter 5: Drawings
Chapter 6: Appendix and Ordering Information
We offer training and introductory courses on request.
I.2 Prescribed usage (“Use as directed”) of the transistor controller
The transistor controllers are intended exclusively for driving DC motors under speed and/or
torque control. The transistor controllers are installed as components in electrical systems or
machines, and it is only permissible to operate them as integral components of these systems or
machines.
Series 04S transistor controllers are operated off the 3-phase industrial mains supply, with
earthing, through an isolating transformer. This isolating transformer must meet the
specification in Chapter IV.1.
The transistor controllers may only be operated in a closed cabinet, observing the ambient
conditions defined in Chapter I.6.2.
The units must be mounted in a standard industrial 19"-rack housing, and contacts may only be
made through one of our module back-panels or a type FH24+7 mating connector.
In accordance with the EC Machine Directive and accident prevention laws, you are obliged to
carry out a hazard analysis of the machine before commissioning the transistor controller.
Chapter I General Page I - 1
Kollmorgen 12.99 Series 04S
Transport : only by personnel which know-how in the handling of
electrostic-sensitive devices.
Installation : only by qualified persons, trained in electrical engineering.
Commissioning: only by qualified persons, with extensive knowledge of
electrical engineering and drive technology.
We can only guarantee the correct functioning of the transistor controller when
our isolating transformers and accessories are used.
We can only guarantee the conformance of the transistor controller with the EC
EMC Directive 89/336/EEC under the condition that only the components shown
in Chapter II are used and that the rules for installation are followed.
