Kolver EDU 2AE/TOP/TA - Page 28

Vers. 270921 Page 28
 CN5 CONNECTOR (25 pin connector - female):
PIN NAME FUNCTION
1 GND
Common to every input. Signals have to be enabled making contact between
the desired signal and this pin
(
common
0VDC).
2
Not used
3 STOP MOTOR OUT
It indicates stop motor is enabled
4 OUTPUT 8
It indicates you’re using program 8
5 OUTPUT 7
It indicates you’re using program 7
6 OUTPUT 6
It indicates you’re using program 6
7 OUTPUT 5
It indicates you’re using program 5
8 OUTPUT 4
It indicates you’re using program 4
9 OUTPUT 3
It indicates you’re using program 3
10 OUTPUT 2
It indicates you’re using program 2
11 OUTPUT 1
It indicates you’re using program 1
12 +24V
+24V available on this pin, they can’t be used to charge external devices.
13 +5V
+5V available on this pin, it can’t be used to charge external devices
14 OK EXT
If enabled (see point 4: OK-ESC, in the option menu), remote OK key
function.
15 ESC EXT
If enabled (see point 4: OK-ESC, in the option menu), ESC key function to
reset
remote errors.
16 RESET EXT
If enabled (see point 4: OK-ESC, in the option menu), it resets program or
sequence according to the preset function (see point 5: Reset, in the option
menu
)
.
17 INPUT 8
Switch – selection of program 8
18 INPUT 7
Switch – selection of program 7
19 INPUT 6
Switch – selection of program 6
20 INPUT 5
Switch – selection of program 5
21 INPUT 4
Switch – selection of program 4
22 INPUT 3
Switch – selection of program 3
23 INPUT 2
Switch – selection of program 2
24 INPUT 1
Switch – selection of program 1
25 +15V
+15V available on this pin, not used to charge external devices
 CN6 CONNECTOR (serial connector 9 pin - male) - FOR BARCODE CONNECTION
PIN NAME FUNCTION
1 +15V
+15V available on this pin, it can’t be used to charge external devices.
2 RX
Serial reception.
5 GND
Common to every input. Signals have to be enabled making contact between
the desired signal and this pin
(
GND
)
9 +5V
Not used.
IMPORTANT: the barcode scanner to be used must have the following features: RS232 transmission with
9600baud, 8 data bits, 1stop bit, no parity, terminators CR-LF.
