Kolver EDU 2AE/TOP/TA - Exploded Views and Spare Parts Lists

Vers. 270921 Page 31
11
“
Error max angle” is displayed on the status bar
(The max preset angle has been reached.
Only
available i
n Tor, T/lv and T/in mode).
12
“
Error angle not OK” is displayed on the status bar
(The preset angle hasn’t been reached. Only
available in Ang., A/lv
and A/in mode).
13
“Warning! No piece” is displayed on the status bar
(
The “missing piece” contact is enabled). -check contact 2 on the CN2 connector
14
“
Compensation error” is displayed on the status bar.
A negative torque value is displayed due to a high
negative compensation value.
- increase or decrease the compensation value
15
In % mode,
"Model not available" is displayed on
the status bar (It has been made an to switch from %
to Unit mode with a screwdriver model not
available)
16
In Unit mode,
"Torque / Speed Error" is displayed on
the status bar. (A torque or speed has been set which
are not included in t
he table relating to the selected
screwdriver)
- set a torque or speed value included in the
range indicated in the table
17
“Released lever error” is displayed on the status bar
(The lever has been released while
tightening).
Such error can be enabled or disabled
through “PROGRAM-MENU” (see point 18
on the program menu).
18
“
Reverse torque error” is displayed on the status
bar (The torque signal
is displayed while
loosening, but only if it’s set on “max”).
- The screwdriver couldn’t loosen
- Avoid motor stalling
- Loosening too heavy
19
“Output Disabled”. Protection of output signals was
activated after exceeding maximum load (400mA).
- Check the set load is not over the allowed
maximum value
- Restart the control unit to reset error
20
“Protection 12A” is displayed on the status bar (it
happens when current on mosfets of bridge H is >
12 A for at least 1 s)
- Decrease screwing time and check settings
- Avoid motor stalling
- Unscrewing too heavy
- Joint too soft
21
“
Protection 14p5A” is displayed on the status bar (it
happens when current on mosfets of bridge H is >
14.5 A for at least 800 ms)
- Decrease screwing time and check settings
- Avoid motor stalling
- Unscrewing too heavy
- Joint too soft
22
“
Protection 15A” is displayed on the status bar (it
happens when current on mosfets of bridge H is > 15
A for at least 500 ms)
- Decrease screwing time and check settings
- Avoid motor stalling
- Unscrewing too heavy
ATTENTION: IF THE OK/ESC OPTION IS DISABLED, ERRORS RESET AT THE
FOLLOWING SCREW/PROGRAM. OTHERWISE PRESS ESC. IF THE PROBLEM PERSISTS,
PLEASE CONTACT YOUR NEAREST KOLVER DEALER.
