Kolver EDU 2AE/TOP/TA

Vers. 270921 Page 39
SPARE PARTS:
Position Description Quantity Code
1 Upper panel EDU2AE/TOP 1 819003
2 3x5 Button head screw burnished TX10 17 872444
3 Motor board 1 852521/SW
4 M3 toothed washer 5 800041
5 Switching 48V 600W 1 872490
6 M3 burnished nut 11 800056
7 I/O EDU 2AE/TOP/E board 1 852525/E
8 M3 brass nut 2 800056/O
9 Ground cable 1 800090/E
10 Ferrite 1 872468
11 Display board EDU2AE/TOP 1 852526
12 Front panel EDU2AE/TOP /E 1 819002/USB
13 Membrane EDU 2AE/TOP/E 1 819004/USB
14 USB Flat cable 1 872474
15 USB Device 1 852424
16 USB Pen drive 1 872475
17 M12 5pin + nut + ferrite connector 1 201666/R1
18 M3 Washer h0,5 mm 4 800042
19 Spacer 15mm dest 4,8 mm 4 890004/T
20 Plastic support 4 800016/B
21 Bottom panel EDU2AE/TOP/SW 1 819001/SW
22 Flat cable 10 vie 1 819007
23 Flat cable 20 vie 1 872438/T
24 Sapcer da 6,3 mm dest 6.2mm 4 241003
25 Fuse 3.15A 2 800619
26 I/O Connector 9 pin spacing 3.81 1 800164
27 I/O Connector 11 pin spacing 3.81 1 800165
28 I/O Connector 14 pin spacing 3.81 1 800166
29 I/O Connector 10 pin spacing 3.81 1 800102
30 Filtered plug 1 800718
31 Main board support 2 872442
Label 1 818006/SW
Schuko Cable 1 800620
