Komatsu D475A-3 - Page 55

.
OPERATION
EXPLANATION OF COMPONENTS
A Basic check items (see CHECK MONITOR GROUP (PAGE 3-7))
Before the engine is started, the basic items among the check before starting items that must be checked are
displayed.
If there is any abnormality, the caution lamp for the location of the abnormality flashes.
NOTICE
When
carrying
out
the
check
before
starting,
do
not
rely
only
on
these
monitors.
Always
carry
out
the
inspection
items
according
to
the
Maintenance
section
or
Section
OPERATION
(PAGE
3-69).
B CAUTION MONITOR GROUP (See "CAUTION MONITOR GROUP (PAGE 3-9)")
CAUTION
If
these
caution
lamp
flash,
check
and
repair
the
appropriate
location
as
soon
as
possible.
These are items, which need to be observed while the engine is running. If any abnormality occurs, items, which
need to be repaired as soon as possible, are displayed.
If there is any abnormality, the appropriate monitor lamp will flash to indicate the location of the abnormality.
C EMERGENCY CAUTION ITEMS (See "EMERGENCY CAUTION ITEMS (PAGE 3-11)")
CAUTION
If
the
caution
lamp
for
any
of
these
items
flashes,
stop
the
engine
immediately
or
run
it
at
low
idling,
and
take
the
following
action.
This displays those of the abnormality items for which action must be taken immediately when the engine is running.
If there is any abnormality, the monitor showing the location of the abnormality will flash and the alarm buzzer will
sound.
D Meter display portion (see METER GROUP (PAGE 3-14))
This consists of the preheating pilot lamp, power train oil temperature gauge, engine water temperature gauge,
hydraulic oil temperature gauge. fuel gauge, dual/single selector display lamp, torque converter lock-up display
lamp, display panel A (speed range display, engine speed) and display panel B (multi-information).
E Mode selection switch panel (see MODE SELECTION SWITCH GROUP (PAGE 3-19))
This consists of the lock-up mode switch, economy mode selector switch and slow reverse mode selector switch.
F Switches (for details, see SWITCH (PAGE 3-35).)
These consist of the starting switch, buzzer cancel switch, front lamp switch, working lamp switch, rear lamp switch,
auto shift down switch, pivot turn switch, information switch, and additional heater switch (option).
F Switches (for details, see SWITCH (PAGE 3-35).)
These consist of the starting switch, buzzer cancel switch, front lamp switch, working lamp switch, rear lamp switch,
auto shift down switch, Preheating switch and information switch.
G Lamps (for details, see LAMP (PAGE 3-24).)
These consist of the warning lamp and filter, oil change interval lamp.
3 - 6
