Kongsberg Simrad RA85 - AIS Specification (Option); Power Supply; Serial Data and Sentence Used

RA83/84/85/93/94/95 Series Chapter 3
Operation Manual Technical Specifications
3.4 AIS specification (Option)
Number of targets displayed Up to 20 activated targets and 20 sleeping targets
Numerical data indication MMSI, CPA, TCPA, CSE/COG, STW/SOG
On screen display
Symbols, target number and vectors.
Indication limit range 1.0 to 6.5 nm
AIS data input To be taken via the AIS connector on the processor rear
panel.
Signal level: RS422
Data format: IEC61162-2
Formatter: ALR, VDO, VDM
3.5 Serial data and sentence used
Serial data: IEC 61162-1 or NMEA 0183 ver 2.0
Sentence: BWC, GGA, GLC, GLL, HDT, RMB, RTE, VBW, VDR, VHW, VTG,
WPL
3.6 Power Supply
Mains Input Voltage: 24 VDC / 32 VDC
Input Voltage Tolerance: 10.8 VDC – 41.6 VDC (for RA83/84/93/94)
21.6 VDC – 41.6 VDC (for RA85/95)
Input Power: 170 W nominal at 24 VDC
Transient Protection:
Specified to the requirements of IEC 60945 4
th
Edition.
Reversed polarity protection: Protected by the Main Fuse.
AC Operation
Rectifier Unit Type PS-010 is required.
Input voltage range: 115/230 VAC
Input voltage tolerance: +/- 10%
Input voltage frequency range: 47 to 63 Hz
Input Power: 220 W
93142105-02 3-3
