Chapter 6 RA83/84/85/93/94/95 Series
Using The Menu Operation Manual
6.1.5 Cursor Position
Indication Meaning
CURSOR T BRG Cursor True or Relative(R) Bearing indication
RNG Cursor Range
LAT Cursor Latitude
LON Cursor Longitude
NOTE: To use this function the heading and latitude/longitude data must be supplied from
the gyro/log interface unit KSA-08A and a GPS or Loran-C navigator unit.
When no bearing data is entered from the gyrocom
ass, the latitude and longitude
display will turn to “XXX.XX.XXX”.
The position data may deviate when a navigator unit is used in latitude above 7
degrees.
CAUTION:
[Data Indication]
OWN SHIP DGPS Own Ship Information (Input Device Name)
(Select with DATA DISP key)
LAT Latitude/COG/LOP1
LON Longitude/SOG/LOP2
WP RT01 DGPS Waypoint Information/Route Name/Input Device
LAT Latitude/Bearing
LON Longitude/Range
XTE Cross Track Error
DEPTH K (W) Depth
NOTE: K means the depth from the Keel, W means the depth from Water surface.
WATER TEMP Water Temperature
6.1.6 Vector Time
The vector indication mode can be set with the TRUE/REL key. A vector time can be
set from the following menu.
Indication Meaning Selection
TRUE (REL) VECT Vector Indication Time OFF, 30SEC, 1MIN,
3MIN, 6MIN, 12MIN,
30MIN, 60MIN
6-4 93142105-02
