Chapter 4 RA83/84/85/93/94/95 Series
Installation OperationManual
APPENDIX 2
Optional cables pinouts and cable color-coding designation
DATA connector pinouts and cable color coding designation:
Cable type name Port name Pin No. Signal name Color code
CW-376-5M DATA 1 Shield Shield, Blue
2 OUT-A White
3 OUT-B Red
4 IN-A Orange
5 IN-B Black
6 GND Green
REMOTE connector pinouts and cable color coding designation:
Cable type name Port name Pin No. A Pin No. B Signal name Color code
CW-561-10M REMOTE 1 7 VIDEO OUT Coax. Black 1D(*)/White
2 8 TRIG OUT Coax. Black 2D(*)/White
3 9 GND Coax. Shield
4 10 AZIP OUT White
5 11 SHF OUT Yellow
6 6 GND Coax. Shield
7 1 VIDEO IN Coax. Black 3D(*)/White
8 2 TRIG IN Coax. Black 4D(*)/White
9 3 GND Coax. Shield
10 4 AZIP IN Green
11 5 SHF IN Blue
12 12 +12V DC NC
NOTE for (*):
1D – 4D: This notation indicates the number of dots printed on the cable jacket.
4-26 93142105-02
