RA83/84/85/93/94/95 Series Chapter 6
Using The Menu Operation Manual
6.2.3.2 PLOT MODE (Plotting Mode)
Indication Meaning Selection
PLOT MODE Plot Mode EPA, ATA
In the RA83/84/85/93/94/95 radar series, the Electronic Plotting Aid (EPA) function is
installed as standard, while the Automatic Tracking Aid (ATA) unit is an optional item.
To use the ATA function, the ATA module (PCB based) must be installed inside the
processor unit.
To use the EPA and ATA functions, the bearing and speed information
must be applied from an external bearing/speed sensor.
CAUTION:
6.2.3.3 TARGET ALL CLEAR (Plotting Target All Clear)
Using this function, all target plots can be cleared. To do so, highlight the “TARGET
ALL CLEAR” sign and press the ENT key.
Indication Meaning Selection
TARGET ALL CLR All plotted targets cleared None
6.2.3.4 ID DISP (ID Number Display)
When this item is set to ON, the target number is indicated beside the target symbol
mark.
Indication Meaning Selection
ID DISP Target ID Display OFF, ON
6.2.3.5 AIS (Automatic Identification Systems) Data Display
This function is available on option basis. For operating details, refer to Para. 6.8
“Operating the AIS.”
6.2.3.6 Navigation Display, Map function
Indication Meaning Selection
NAV ALIGN MODE Navigation Display Align Mode OFF, MANUAL, SERIAL
MAP Map Display OFF, ON
MAP DATUM Map Display Datum
NONE, WGS84, WGS72,
SGS85, PE90
GPS DATUM GPS Datum See NOTE
REFERENCE
LOCAL
NOTE: The GPS DATUM (REFERENCE or LOCAL) is shown only when SERIAL is
selected as NAV ALIGN MODE.
93142105-02 6-9
