6.2.3.7 TM RESET (True Motion Center Reset)
When this function is activated, the picture center position is reset to the position
designated by the SYSTEM/SYS SETUP/TM RESET menu.
Indication Meaning Selection
TM RESET True Motion Center Reset No choice
6.2.3.8 OS PAST CRS (Own Ship's Past Course)
When this function is selected, the course own ship has traveled past is displayed in a
line form plotted at a predetermined interval.
Indication Meaning Selection
OS PAST CRS Own Ship's Past Course OFF, EVERY, 15SEC,
30SEC, 1MIN, 3MIN,
6MIN, 12MIN
6.3 ADJUST MENU
The ADJUST menu has two sub menus; ADJUST and PRESET.
Details of each sub menu are as follows:
6.3.1 ADJUST
6.3.1.1 Screen Contrast Settings
Indication Meaning Selection
VIDEO CONTR Radar Video Contrast 0 to 99
Changes the brilliance of the radar echo presentation.
Indication Meaning Selection
MARKER CONTR Marker Contrast 0 to 99
Changes the brilliance of various markers, Parallel Cursor, Heading Line, Alarm Zone,
and Cross Cursor.
Indication Meaning Selection
PLOT CONTR Plot Contrast 0 to 99
Changes the brilliance of plotting symbols and ID number used for the EPA and ATA
functions.
Indication Meaning Selection
DATA CONTR Data Contrast 0 to 99
Changes the brilliance of texts and graphics outside the PPI screen.
6-10 93142105-02
