RA83/84/85/93/94/95 Series Chapter 4
Operation Manual Installation
93142105-02 4-11
Screw covers (4 pcs)
Figure 4.12 Installing the Operation Unit onto the panel
M4 Tapping-screws (4 pcs)
Operation Unit
Mounting bracket
Figure 4.11 Removing the Operation
Unit from the Mounting Bracket
Screw covers (4 pcs)
M4 screws (4 pcs)
To Next Page
