Chapter 4 RA83/84/85/93/94/95 Series
Installation OperationManual
Main Logic PCB. (Refer to the figure A.2)
(7) Reconnect all cables to the Main Logic PCB.
Cable connecting list
No. KSA-08A (E47-510A) Main Logic PCB (E47-700*)
1 J512 J708
2 J515 J707
3 J517/518 J718
GYRO connector pinouts and cable color coding designation:
Cable type name Port name Pin No. Signal name Color code
CW-388-5M GYRO 1 S1 Red dot/Orange
2 S2 Black dot/Orange
3 S3 Red dot/Grey
4 R1 Red dot/White
5 R2 Black dot/White
6 COM Red dot/Yellow
7 GND Shield
8 LOG1 Red dot/Pink
9 LOG2 Black dot/Pink
10 NC
4-24 93142105-02
