Before Making Copies
3
3-11
Shifting Unit
Job Tray
No. Part Name Description
12 Copy Tray Receives copy sets sorted.
No. Part Name Description
13 Copy Tray Lamp Lights up when paper is fed into the Upper Copy Tray.
14 Upper Copy Tray Receives printed pages produced via the personal
computer or faxes received.
15 Lower Copy Tray Receives copies made.
15
14
13
12
When Job Tray is Mounted
