40 Part Number STH063 9/17
REMOVE PARTS FOR CLEANING
n
Warning
Disconnect electric power to the ice machine at the
electric switch box before proceeding.
1. Remove the water curtain
• Gently flex the curtain in the center and remove it
from the right side.
• Slide the left pin out.
2. Remove the water trough
• Depress tabs on right and left side of the water
trough.
• Allow front of water trough to drop as you pull
forward to disengage the rear pins.
3. Remove the ice thickness and harvest float switches
• Pull the float switch straight down to disengage.
• Lower the float switch until the wiring connector
is visible.
• Disconnect the wire lead from the float switch.
• Remove the float switch from the ice machine.
4. Remove the water distribution tube
NOTE: Distribution tube thumbscrews are retained
to prevent loss. Loosen thumbscrews but do not pull
thumbscrews out of distribution tube.
• Loosen the two outer screws (do not remove
screws completely they are retained to prevent
loss) and pull forward on the distribution tube to
release from slip joint.
• Disassemble distribution tube by loosening the
two (2) middle thumbscrews and dividing the
distribution tube into two pieces.
• Proceed to page 38 Step 6.
To Next Page
