■ Specifications
<Recorder section>
< MIDI functionality >
<Mixer section>
<Effect section>
<General>
■ Principal specifications
■ Analog/digital input and output specifications
<INPUT1, 2, 3, 4>
<INPUT5, 6, 7, 8>
<GUITAR INPUT>
<MASTER OUTPUT L/R>
<MONITOR OUTPUT L/R>
D1600 specifications
Operating temperature
range:
+5 – +35 degrees C (do not allow con-
densation)
Number of tracks: 128 tracks (including virtual tracks)
16 tracks simultaneous playback, 8
tracks simultaneous recording @ 16
bits
8 tracks simultaneous playback, 4
tracks simultaneous recording @ 24
bits
Recording format: 24 bit/16 bit uncompressed, 44.1 kHz
Recording time: 16 bit recording: maximum 62 hours
24 bit recording: maximum 31 hours
*
When internal 20 Gbyte hard disk is used
Maximum storage
capacity:
internal + external 1,000 Gbytes × 7
drives
Number of songs: 100 songs per drive
Locate points: four points per song
Mark points: 100 points per song (marks can be
named)
Metronome patterns: 96
Rhythms: 215
MMC functions: Transmitted and received
Synchronization: MTC transmission/reception, MIDI
Clock transmission
Tempo map (200 points per song)
Sync track (1 track per song)
Tempo rec
CD-R/RW functional-
ity:
Create audio CD, backup/restore,
import WAV file (ISO 9660)
SCSI functionality: Recording/playback/copy song
(playable), create audio CD, backup/
restore, import (FAT 16, ISO 9660)/
export (FAT 16) WAV file
Track editing: Copy, insert, erase, delete, swap,
reverse, time expansion/compres-
sion, fade, normalize, optimize (tracks
can be copied between songs)
Song editing: Copy, move, delete, rename, protect
Counter/locate format: Min/Sec/mSec, Meas/Beat/Tick,
Min/Sec/Frame (30NDF only)
MIDI functionality: Mixer control, effect control, MMC
transmission/reception, MTC trans-
mission/reception, MIDI Clock trans-
mission
Structure: 24 channel input, 8 BUS, 1 AUX, 1
MASTER
Signal processing: 32 bit 44.1 kHz
Equalizer: HIGH (f:10 kHz G:±15 dB)
MID (f:0.1 –20 kHz G:±15 dB)
LOW (f:100 Hz G:±15 dB)
Scene memory: 100 scenes per song
Structure: insert × 8 (maximum)
master × 2 (maximum)
final × 1
All usable simultaneously
Signal processing: 44 bit 44.1 kHz
Programs: insert (128 preset, 128 user)
master (32 preset, 32 user)
final (32 preset, 32 user)
Algorithms: 98
Effects: 106
Display: 240 × 64 pixel
LCD with backlight and touch panel
Power consumption: 31 W (with HDD-20G installed)
38 W (with HDD-20G, CDRW-2
installed)
Dimensions: 510mm (W) × 363 mm (D) × 138 mm
(H) (Including protrusions)
Weight: 6.0 kg (main unit only)
7.8 kg (with HDD-20G, CDRW-2
installed)
Frequency response: 10 Hz –20 kHz ±1dB @+4 dBu, 10 kΩ
load
S/N: 96 dB (typical) @IHF-A
Dynamic range: 96 dB (typical) @IHF-A
THD+N: 0.02 % (typical) 20 Hz –20 kHz @+16
dBu, 10 kΩ load
A/D conversion: 24 bit, 64 times oversampling
D/A conversion: 24 bit, 128 times oversampling
Sampling frequency: 44.1 kHz
Connectors: XLR-3-31 type (+48V phantom power,
SW), 1/4" TRS phone jack (balanced)
Input impedance: 4 kΩ/XLR-3-31, 10 kΩ/TRS phone
jack
Nominal level: –60 dBu @TRIM=max.
+4 dBu @TRIM=min.
Maximum level: –48 dBu @TRIM=max.
+16 dBu @TRIM=min.
Source impedance: 600 Ω
Connectors: 1/4" TRS phone jack (balanced)
Input impedance: 10 kΩ
Nominal level: –60 dBu @TRIM=max.
+4 dBu @TRIM=min.
Maximum level: –48 dBu @TRIM=max.
+16 dBu @TRIM=min.
Source impedance: 600 Ω
Connector: 1/4" phone jack (unbalanced)
Input impedance: 1 MΩ
Nominal level: –60 dBu @TRIM=max.
+4 dBu @TRIM=min.
Maximum level: –48 dBu @TRIM=max.
+16 dBu @TRIM=min.
Source impedance: 600 Ω
Connector: 1/4" phone jack (unbalanced)
Output impedance: 150 Ω
Nominal level: –10 dBu
Maximum level: +2 dBu
Load impedance: 10 kΩ or more
Connector: 1/4" phone jack (unbalanced)
Output impedance: 150 Ω or more
Nominal level: –10 dBu
Maximum level: +2 dBu
Load impedance: 10 kΩ or more
