MIDI implementation chart
Consult your local Korg distributor for more information on MIDI IMPLEMENTATION.
Variable Range
MIDI Implementation Chart
Basic
Channel
Default
Changed
Aftertouch
Pitch Bend
Polyphonic (Key)
Monophonic (Channel)
Program
Change:
System
Real Time
: Clock
: Command
System Exclusive
System
Common
: Quarter frame
: Song Position
: Song Select
: Tune
Mode 1: OMNI ON, POLY Mode 2: OMNI ON, MONO : Yes
Mode 3: OMNI OFF, POLY Mode 4: OMNI OFF, MONO : No
Aux
Messages
: Local On/Off
: All Notes Off
: Active Sense
: Reset
Velocity
Note On
Note Off
Note
Number:
True Voice
Mode
Memorized
Messages
Altered
Control
Change
Function Transmitted Recognized Remarks
Date : 2000. 8. 4
Model D1600
0 —119
Scene numbers 1–100
Received/transmitted only for 30 frame non-drop
Notes
[ Digital Recording Studio ]
Effect control (reception only)
All control numbers #000-119 are received
Mixer control (transmission/reception)
07 Fader
10 Pan
12,13 EffSend1/2
14 AuxSend
16,19,20,25 Eq Low/Mid/MidFc/Hi
68,71,72,77 InEq Low/Mid/MidFc/Hi
80,81,82,83 SubIn Lev/Bal/Mono/Mute
86,87 MstEff1 RetLev/RetBal
88,89 MstEff2 RetLev/RetBal
08,94 ChannelPair/Function
95 Master fader
*1: Received if “MMC Mode: Receive” is selected in [SYSTEM] “MMC.”
*2: Transmitted if “MTC Mstr” is selected in [SYSTEM] “Sync.”
*3: Transmitted if “Clock Mstr” is selected in [SYSTEM] “Sync.”
*4: Received if “MIDIClock” is selected for “SelectRecTempoTrackType” in
[TEMPO/RHYTHM] “TmpTrk,” and tempo is being recorded.
*5: Received to control effects when selected in [SYSTEM] “Control.”
*6: Transmitted/received for mixer control when ControlChange is
enabled in [SYSTEM] “MIDI.”
*7: Transmitted/received if ProgChange is enabled in [SYSTEM] “MIDI.”
*8:
Transmitted if “MMC Mode: Transmit” is selected in [SYSTEM] “MMC.”
*9: Received if “MIDISync Mode: MTC Slave” is selected in [SYSTEM]
“Sync.”
