Korg D1600 - Block diagram

141
<AUX OUTPUT>
<PHONES OUTPUT>
<S/P DIF INPUT/OUTPUT>
<SCSI>
<MIDI IN/OUT>
<FOOT SW>
<EXPRESSION PEDAL>
■ Accessories
■ Options
• For other recommended drives, please contact your Korg dis-
tributor.
* Appearance and specifications of this product are subject to
change without notice. (Nov./2000)
Connector: 1/4" phone jack (unbalanced)
Output impedance: 150 Ω
Nominal level: –10 dBu
Maximum level: +2 dBu
Load impedance: 10 kΩ or more
Connector: 1/4" stereo phone jack
Output impedance: 100 Ω
Maximum level: 50 mW @32 Ω
Connector: optical
Format: 24 bit S/P DIF (IEC60958, EIAJ CP–
1201)
Connector: HD SCSI-2 (D-sub half-pitch 50 pin)
Format: SCSI-2 compatible
Connectors: DIN 5 pin × 2
Connector: 1/4" phone jack (use separately sold
PS-1)
Connector: 1/4" stereo phone jack
(use separately sold XVP-10 or EXP-2)
:
:
:
Power cable
Owner’s Manual
Demo song backup CD
:
:
:
:
:
PS-1 pedal switch
XVP-10 EXP/VOL pedal
EXP-2 foot controller
CDRW-2 CD-R/RW drive
(internal type)
HDD-20G 20GB hard disk drive
(internal type)
Appendices
D1600
specifications
