Korg KRONOS 88

500475104091 HARNESS HNS-4091 1
500475104092 HARNESS HNS-4092 1
500475104093 HARNESS HNS-4093 1
500475104096 HARNESS HNS-4096 1
500475004231
HARNESS
HNS-4231
EUP
D
1
*5)
500642000030
X09130 VJS KNOB C41705
1
1
1
500646100789 X09130 SIDE PANEL-L E30572-1 1
500646100790 X09130 SIDE PANEL-R E30572-2 1
500646100771
X09131 SIDE PANEL-L E30573-1
1
1
500646100772
X09131 SIDE PANEL-R E30573-2
1
1
500646100773
X09130 LCD HOOD E30575
1
1
1
500540028944
X09131 LCD SPACER F41729
1
1
500646100774
X09130 JS PANEL E30576
1
1
1
500646100776
X09130 KB COVER E30579
1
500646100775
X09131 KEY BLOCK E30577
1
1
500646100777
X09130 VJS FRAME E40801
1
1
1
500646100782 X09130 REFLECTOR-5 E40804-5 1 1 1
500620049729
X09130 KEY-S-4 E40802-4
2
2
2
500620049733
X09130 KEY-L-4 E40803-4
6
6
6
500620049735
X09130 ENCODER KNOB E40800
1
1
1
500620049736
X09130 SVR KNOB-B/G E40805-2
10
10
10
500541000001
X09130 VJS SHEET-L F41627
1
1
1
500541000002
X09130 VJS SHEET-S F41628
1
1
1
500550023530
X09131 KB FELT F41629-1
1
500550023531
X09132 KB FELT F41629-2
1
500646100764
X5870 VR KNOB(H) E30459-1
10
10
10
500620044800
ROTARY VR KNOB KOC-E48026-1
2
2
2
500620018200
POWER SW KNOB KOC-E40224
2
2
2
500500022500
FF-004-AR791
5
500500037007
RUBBER FOOT K-24W
5
5
500646100791
X09130 JS REFLECTOR E40747-2
1
1
1
500540028940
TOUCH PANEL TAPE S F41638-2
2
2
2
500540028939
TOUCH PANEL TAPE L F41638-1
2.25
2.25
2.25
500641042122
X07111 ANGLE-S C41573
2
2
2
500642000028
X09130 FRONT BAR C41697
1
500642000029
X09131 FRONT BAR C30841-1
1
500642000032
X09132 FRONT BAR C30841-2
1
*2)Change in service manual Ver 1.4
*a)QTY=1:Before DIMM extension
QTY=2:If supported DIMM extension
*3) It is necessary to write the system in the factory.
*4) 200109263008(PCB Ass'y) is the same as the one that is included in 200129603005&200129613005
*5) It is the part that was added in service manual V2.0
JoyStic unit
Part Number Category Part Name Location Reference
500362009052
VR
RK11K1140D1H
VR9-10
2
2
2
200062462704
PCB ASSY
KLM-2704/2705
0.25
0.25
0.25
500646100703
X4100 JS COVER E40702-2
1
1
1
500646100068
X4100 JS W HEEL E40703
1
1
1
500646100070
X4100 JS W HEEL SUPPORT E30455
1
1
1
500646100071
X4100 JS FRAME E30456
1
1
1
500646100069
X4100 JS PLATE E40704
1
1
1
500644010500
X-0100 WHEEL SPRING KOC-C41222
2
2
2
500540026500
X-0100 JS W ASHER KOC-F40979
2
2
2
Remodeling to change mother board from D510MO to D525MW
(note)Don't use BLKD525MW on the market.
Part Number
Category
Part Name
Location
Reference
QTY
61
73
88
200002189801 MOTHER BOARD BLKD525MW (SPARE)
Assembled following parts and
custamized BIOS.
500520001700 CR2032-A1//Z
500540028943 63429-202LF
500565001500 HH-AA-A-
P(HARD 20X20)
500565001600 HT-B-A-A(TAPE
20X20)
1 1 1
500002191100
MEMORY MODULE
SO-DIMM SMD-N2G68H1P-13H
*a)
*a)
*a)
200109263008
Boot suport BOARD
KLM-3008 KRONOS/X(FOR
1
1
1
*5)
500641042208
Side Chassis
X11150 SideChassis-R
C30849-6
1
500630042661
Shield sheet
X11151 MB SHIELD2 F41788
2
2
500475004186
HARNESS
HARNESS FOR ENO-1612(D525MW )
1
1
1
*1)Note: The KLM-3101 is used only for J03, J04, and J05 lot (some for J06lot as well).
*a)QTY=1:Before DIMM extension
QTY=2:If supported DIMM extension
*5) It is the part that was added in service manual
V2.0
QTY
