Korg Pa50 User Manual

123
Program operating mode
AMS (Alternate Modulation Source) list
AMS (ALTERNATE MODULATION SOURCE) LIST
Flt KTrk +/+ (Filter Keyboard Track +/+)
Flt KTrk +/– (Filter Keyboard Track +/–)
Flt KTrk 0/+ (Filter Keyboard Track 0/+)
Flt KTrk +/0 (Filter Keyboard Track +/0)
Amp KTrk +/+ (Amp Keyboard Track +/+)
Amp KTrk +/– (Amp Keyboard Track +/–)
Amp KTrk 0/+ (Amp Keyboard Track 0/+)
Amp KTrk +/0 (Amp Keyboard Track +/0)
+/+ The direction of the effect will be determined
by the sign (positive or negative) of the “Ramp
Low” or “Ramp High” setting.
+/– The direction of the effect will be determined
by the sign of the “Ramp Low” setting, and by
the opposite sign of the “Ramp High” setting
(–50 for a setting of +50, and +50 for a setting
of –50).
0/+ “Ramp Low” will have no AMS effect. The sign
of the “Ramp High” setting will determine the
direction of its effect.
Off Do not use Alternate Modulation
Pitch EG Pitch EG
Filter EG Filter EG within the same oscillator
Amp EG Amp EG within the same oscillator
LFO1 LFO1 within the same oscillator
LFO2 LFO2 within the same oscillator
Flt KTrk +/+ (Filter Keyboard Track +/+) Filter keyboard tracking within the same oscillator
Flt KTrk +/– (Filter Keyboard Track +/–) Filter keyboard tracking within the same oscillator
Flt KTrk 0/+ (Filter Keyboard Track 0/+) Filter keyboard tracking within the same oscillator
Flt KTrk +/0 (Filter Keyboard Track +/0) Filter keyboard tracking within the same oscillator
Amp KTrk +/+ (Amp Keyboard Track +/+) Amp keyboard tracking within the same oscillator
Amp KTrk +/– (Amp Keyboard Track +/–) Amp keyboard tracking within the same oscillator
Amp KTrk 0/+ (Amp Keyboard Track 0/+) Amp keyboard tracking within the same oscillator
Amp KTrk +/0 (Amp Keyboard Track +/0) Amp keyboard tracking within the same oscillator
Note Number Note number
Velocity Velocity
Poly AT (Poly After Touch)
(a)
(a) After Touch data can only be received via MIDI, or create as a MIDI event in Song Record-Step Recording mode.
Polyphonic After Touch (transmitted from the Pa50 only as sequence data)
Channel AT (Channel After Touch)
(a)
After Touch (Channel After Touch)
Joystick X Joystick X (horizontal) axis
Joystick +Y Joystick +Y (vertical upward) direction (CC#01)
Joystick –Y Joystick –Y (vertical downward) direction (CC#02)
JS+Y & AT/2 (Joy Stick +Y & After Touch/2)
(a)
Joystick +Y (vertical upward) direction and After Touch
JS–Y & AT/2 (Joy Stick –Y & After Touch/2)
(a)
Joystick –Y (vertical downward) direction and After Touch
Ass.Pedal Assignable foot pedal (CC#04)
CC#18 CC#18
CC#17 CC#17
CC#19 CC#19
CC#20 CC#20
CC#21 CC#21
Damper Ddamper pedal (CC#64)
CC#65 Portamento switch (CC#65)
Sostenuto Sostenuto pedal (CC#66)
CC#80 CC#80
CC#81 CC#81
CC#82 CC#82
CC#83 CC#83
Tempo Tempo (tempo data from Sequencer 1 clock or external MIDI clock)

Korg Pa50 Specifications

General

Type	Arranger Keyboard
Polyphony	62 voices
User Styles	48
MIDI	In, Out, Thru
Keyboard	61 keys
Timbres	16
ROM	32 MB
Performances	160
Effects	4 stereo digital multi-effect systems
Sequencer	16-track
Song Play	Yes
Display	Backlit LCD
Outputs	L/Mono, R, headphones
Inputs	Damper Pedal, Assignable Pedal/Switch
Floppy Disk	3.5"
Storage	Internal and floppy disk
Connections	Sustain pedal, assignable pedal
Amplification	2 x 15 Watts
Speakers	2 x 10 cm
Sound Engine	HI (Hyper Integrated) Synthesis System
