Pa60 Specifications
Keyboard
61 notes with Velocity
System
OPOS – Objective Portable Operating System: multitasking system, load while playing
feature. Upgradable Operating System. SSD Solid State Disk
Tone generator
HI Synthesis (Hyper Integrated Synthesis System) – 62 Voices, 62 Oscillators – Filters
with Resonance
Waveform Memory
32 Mbyte PCM ROM (Stereo Piano Sound)
Effects
4 Stereo Digital Multi-Effect systems (89 Effects available)
Programs
More than 660 Programs (including Stereo Piano and GM Level 2 Programs). 32 Drum
Kits.128 User Programs + 64 User Drum Kits. Full edit feature for Programs and Drum
Kits
Styles
Up to 304 styles in solid state disk. All reconfigurable. 8 accompaniment tracks. 48 user
Styles. All Style Performances are programmable (included 4 Single Touch Settings for
each style). Direct Floppy Disk/Direct Hard Disk (optional) feature. Compatible with old
i-series style format. Style Record with Edit functions, Step Edit, Event Edit
Styles Controls
4 Variations, 2 Fills, 2 Intros, 2 Endings, Counter In/Break, Synchro Start/Stop, Tap
Tempo/Reset, Fade In/Out, Bass Inversion, Manual Bass, Tempo Lock, Memory,
Accompaniment Volume, Accompaniment Mute, Drum Mapping, Snare & Kick
Designation, Single Touch
Performance
160 real-time Performances + up to 304 Styles Performances (that contains 4 Single
Touch Settings each)
General Controls
Master Volume, Ensemble, Octave Transpose, Master Transpose, Split Point, Style
Change, Tracks Volume, Quarter Tone Function, Programmable Slider, Joystick, Dial
Multi PAD
4 assignable (both sound or functions) Pads + Stop button
Song Play
XDS* Crossfade Dual Sequencer player – 2 Sequencers with separate Start/Stop,
Pause, ‘<< Rew’ and ‘>> FF’ controls. Balance control. Lyrics are displayed on-screen.
Jukebox Function. SMF Direct Player (format 0 and 1)
Song
Song Record, Song Edit, Event Edit, Step Edit – Easy Sound Edit - 16 Tracks – SMF
format
Backing Sequence
Easy Record – 16 Tracks – SMF format – Step Chord/Acc Edit
Control Inputs
Damper Pedal, Assignable Pedal/Switch
Audio Outputs
Left/Mono, Right
Audio Inputs
Left/Mono, Right (Line Input)
MIDI
In, Out, Thru
Floppy Disk
3.5 inch 2DD/2HD (Ms-Dos? compatible)
Hard Disk
Optional Hard Disk (with installation kit)
Display
Backlit Custom LCD
Main Amplifier
2 x 15 Watt
Speakers
2 x 10 cm Double-Cone Speakers in Bass Reflex Box
Power Consumption
30 Watt
Dimensions
W = 1110mm, D = 388mm, H = 164mm without music rest
Weight
13.5 kg
Accessories
Music Rest
Options
HDIK Hard Disk Installation Kit, VIF2 Video Interface Kit, EXP-2 Exp/Volume Pedal,
XVP-10 Exp/Volume Pedal, PS-1 Footswitch, DS-1H Damper Pedal
Specification and design are subject to change without notice for the purpose of product enhancement.

Korg PA60 Specifications

General

Outputs	L/Mono, R, Headphones
MIDI	In, Out, Thru
Weight	12.5 kg
Keyboard	61 keys with velocity
Polyphony	62 voices
Sound Engine	HI synthesis
ROM	32 MB
Styles	304 styles
Performances	160 performances
Effects	2 stereo digital multi-effect systems
Sequencer	16-track
Inputs	Assignable pedal/switch
Storage	3.5" floppy disk drive
Sequencer Memory	100, 000 notes
Connections	MIDI (In, Out, Thru)
Power Supply	AC adapter (included)
Effects Detail	Reverb (8 types), Chorus (8 types), Delay (8 types)
