FV = FULL VIEW D = Pa80 DISASSEMBLY LD1 = LOWER CASE DISASSEMBLY 1 LD1 = LOWER CASE DISASSEMBLY 2
UD1 = UPPER CASE DISASSEMBLY 1 UD2 = UPPER CASE DISASSEMBLY 2 UD3 = UPPER CASE DISASSEMBLY 3
UD4 = UPPER CASE DISASSEMBLY 4 PSS = POWER SWITCHING SUPPLY MB = MAIN BOARD GROUP
FD = FLOPPY DISK GROUP OB = OUTPUT BOARD
PART LIST SCREWS
CODE PART-TYPE REFERENCE kgf per cm QTY
VTA0001002 4x12TFR ZN PR LD1 12 1
VTA0001004 4x15 TFR ZN PR D LD2 10 – 12 8
VTA0001005 3Mx10 TC ZN PSS 6 4
VTA0001010 3x16TC ZN PR D UD3 8 – 10 12
VTA0001011 GROVER Ø 4mm LD1 PSS 3
VTA0001032 3Mx8 TC ZN MB OB UD1 6 – 8 – 6 7
VTA0001034 4x20 TC PR ZN LD1 LD2 12 27
VTA0001037 2,9x6,5 TC SELFTHREADING NERE SP MB OB 8 10
VTA0001038 3x8 TC PR TROP.SP UD1 UD3 8 – 6 41
VTA0001039 2.9x9.5TC SELFTHREADING ZN SP D UD1 UD4 8 9
VTA0001040 4,2x8 TFR SELFTHREADING TROP. SP LD1 LD2 12 7
VTA0001046 3Mx6 TC SELFTAPPING PSS FD 10 – 6 6
VTA0001049 2,2x6,5 TC ZN OB 6 6
VTA0001050 M4x8 TC SELFTAPPING LD1 PSS 15 3
VTA0001051 3x13 TC PR ZN LD1 LD2 UD2 8 13
VTA0001060 2.9x9.5 TSP ZN PSS 6 2
VTA0001067 3.5x16 TC AGG-BZ D 10 9
VTA0001068 2.9x16 TC ZN UD3 6 4
OTHER PARTS
CODE PART-TYPE REFERENCE QTY
ALT0001015 WIDE RANGE SPEAKER LD1 2
BOB0001001 FERRITE RT25-150-120-K5B LD1 UD1 2
TAS0001005 KEYBOARD TP7 UD3 1
TRA0004003 POWER SWITCHING SUPPLY PSS 1
FEL0001022 FIBERFORM 62 TE 200X200x40 LD2 2
FEL0001029 3M 18m.m. ADHESIVE TAPE LD1 UD1 UD3 FD 0.6 m
FEL0001030 BUMPON 3M ART.SJ5023 LD2 6
FEL0001034 1.5x13x1200 ADHESIVE RUBBER LD2 1
FEL0001035 1.5X13X250 ADHESIVE RUBBER LD1 2
FEL0001040 5X10X30 ADHESIVE RUBBER LD2 2
FEL0001052 16X40X1 ADHESIVE FELT LD1 7
FEL0001055 AD-30M (177.2X182X4) FILTER UD4 2
FEL0001056 12mm DOUBLE SIDE ADHESIVE TAPE 1,32 m
FEL0001058 68X25X5 ADHESIVE RUBBER UD3 MB 2
FEL0002037 PA60 SERIAL NUMBER LD2 1
FEL0001077 FDD-MAINBOARD SHIELD MB 1
FDD0002005 DISPLAY GROUP 901- RI.CO UD4 1
FDD0001014 BLACK JOYSTICK UD3 1
FDD0001001 FLOPPY D.D. LOW NOISE FD 1
