Korg PA60 Service Manual

FV = FULL VIEW D = Pa80 DISASSEMBLY LD1 = LOWER CASE DISASSEMBLY 1 LD1 = LOWER CASE DISASSEMBLY 2
UD1 = UPPER CASE DISASSEMBLY 1 UD2 = UPPER CASE DISASSEMBLY 2 UD3 = UPPER CASE DISASSEMBLY 3
UD4 = UPPER CASE DISASSEMBLY 4 PSS = POWER SWITCHING SUPPLY MB = MAIN BOARD GROUP
FD = FLOPPY DISK GROUP OB = OUTPUT BOARD
Pa60 PART LIST
PART LIST ELECTRIC COMPONENTS
CODE PART-TYPE DESCRIPTION QTY
GRA0002014 PCB ASSEMBLY KIP-2014 PANEL BOARD 1
GRA1002027 PCB ASSEMBLY KIP-2027 PANEL CONTROLLER 1
GRA0002054 PCB ASSEMBLY KIP-2054 OUTPUT BOARD 1
GRA0002055 PCB ASSEMBLY KIP-2055 DIGITAL AMPLIFIER 1
GRA0002034 PCB ASSEMBLY KIP-2034 ROTARY ENCODER 1
GRA0002025 PCB ASSEMBLY KIP-2025 MAIN BOARD 1
GRA0002038 PCB ASSEMBLY KIP-2038 MAIN FILTER 1
PART LIST PANEL BOARD KIP-2014
CODE PART-TYPE REFERENCE QTY
DIX0005300 SIGNAL DIODE 1 N 4148 D1-70 70
INT0001008 SWITCH SW1-70 70
LED0001002 RED LED 2mm WITH SPACER DL1-16 DL18-33 32
LED0005002 BICOLOR LED 3mm red/green DL17 1
POT0001003 LIN. POTENTIOMETER 10KBX2 PAR.P VR1 1
POT0001004 LIN. POTENTIOMETER 10KB PAR.POL VR2-3 2
POT0001008 LIN. POTENTIOMETER 10KB 45mm VR4 1
TRS0001001 NPN DIGITAL TRANSISTOR Q1-5 5
PART LIST PANEL CONTROLLER KIP-2027
CODE PART-TYPE REFERENCE QTY
BOB0005002 EMI FERRITE BLM21B102SPT L1-85 85
CIN0002012 I.C. TC74HC138 AFN SMD IC2 IC4-5 3
CIN0002041 I.C. SW/LED/KBD SCANNER (NKS3) IC1 1
CIN0002043 I.C. HCF74HC4053D SMD IC3 1
DIX0006000 DOUBLE DIODE SMD DA204KT146 DD1-2 2
DIX0006003 DIODE SMD RLS-4148 D1-12 12
INT0001008 SWITCH SW1-12 12
LED0005001 RED LED 2mm WITH SPACER LD1-8 LD10 9
LED0005002 BICOLOR LED 3mm red/gree DL1 1
QUA0005003 CER. RESONATOR 16 Mhz 3 PIN X1 1
TRS0002001 NPN TRANSISTOR DTC114EKA SMD Q1-3 3
TRS0002002 PNP TRANSISTOR DTA114EKA SMD Q4-11 8
PART LIST OUTPUT BOARD KIP-2054
CODE PART-TYPE REFERENCE QTY
BOB0005001 EMI SUPP. COIL VK200 L1-2 2
BOB0005002 EMC COIL SMD L3-8 L16-22 13
BOB0005003 EMI FILTER DST310 L15 1
CIN0001009 DUAL HEADPH.OP. AMP. U1 1
CIN0001012 PHOTOCOUPLER IC2 1
CIN0001020 HEX INV IC1 1
CIN0001021 BA15218 DUAL LOW NOISE OP. AMP. IC3-4 2
DIX0005300 1N4148 H. SPEED SW. DIODE D1-5 5

Korg PA60 Specifications

General

Outputs	L/Mono, R, Headphones
MIDI	In, Out, Thru
Weight	12.5 kg
Keyboard	61 keys with velocity
Polyphony	62 voices
Sound Engine	HI synthesis
ROM	32 MB
Styles	304 styles
Performances	160 performances
Effects	2 stereo digital multi-effect systems
Sequencer	16-track
Inputs	Assignable pedal/switch
Storage	3.5" floppy disk drive
Sequencer Memory	100, 000 notes
Connections	MIDI (In, Out, Thru)
Power Supply	AC adapter (included)
Effects Detail	Reverb (8 types), Chorus (8 types), Delay (8 types)
