Korg PA60 Service Manual

FV = FULL VIEW D = Pa80 DISASSEMBLY LD1 = LOWER CASE DISASSEMBLY 1 LD1 = LOWER CASE DISASSEMBLY 2
UD1 = UPPER CASE DISASSEMBLY 1 UD2 = UPPER CASE DISASSEMBLY 2 UD3 = UPPER CASE DISASSEMBLY 3
UD4 = UPPER CASE DISASSEMBLY 4 PSS = POWER SWITCHING SUPPLY MB = MAIN BOARD GROUP
FD = FLOPPY DISK GROUP OB = OUTPUT BOARD
PART LIST PLASTIC COMPONENTS
CODE PART-TYPE REFERENCE QTY
PLA0001037 BASS REFLEX TUBE LD2 2
PLA0001046 SMALL CABLE HOLDER LD1 UD3 MB 4
PLA0001047 BIG CABLE HOLDER LD1 1
PLA0001052 MAIN BLACK SWITCH LD2 1
PLA0001062 FCV-100 PAN TY CABLE TIE LD1 UD1 3
PLA0001036 PLT1-M PAN TY CABLE TIE UD3 1
PLA0001080 POTENTIOMETER KNOB D 4
PLA0001081 RUBBER KNOB UD4 81
PLA0001085 DIAL KNOB D 1
PLA0001091 START STOP SWITCH UD4 1
PLA0001121 BLACK PLUG LD1 1
PLA0002044 LOWER CASE LD1 1
PLA0002045 UPPER CASE UD4 1
PART LIST HARNESSES
CODE PART-TYPE REFERENCE QTY
RIL0001030 MASTER VOLUME UD1 1
RIL0001040 PLUG 1
RIL0001123 AMPLIFIER LD1 1
RIL0001126 ROTARY ENCODER UD3 1
RIL0001127 FDD/CPU SUPPLY UD1 MB 1
RIL0001130 GROUND PSS 1
RIL0001132 SCAN/CPU FLAT CABLE UD2 UD3 1
RIL0001133 SIGNAL FLAT CABLE UD1 MB 1
RIL0001135 PANEL-A FLAT CABLE UD3 1
RIL0001136 PANEL-B FLAT CABLE UD3 1
RIL0001137 KEYB/CPU-A FLAT CABLE UD3 1
RIL0001138 KEYB/CPU-B FLAT CABLE UD3 1
RIL0001139 FDD/CPU FLAT CABLE UD1 MB 1
RIL0001140 LCD FLAT CABLE UD2 UD4 1
RIL0001141 LCD SWITCH FLAT CABLE UD3 UD4 1
RIL0001177 SPEAKERS LD1 2
RIL0001178 PT45C/AMPLIF. LD1 1
RIL0001184 MAIN BOARD GND LD1 1
RIL0001190 CPU SUPPLY LD1 1
RIL0001191 AUDIO SIGNAL FLAT CABLE UD1 MB 1
RIL0001119 MAIN INPUT PSS 1
RIL0001131 MAIN OUTPUT PSS 1

Korg PA60 Specifications

General

Outputs	L/Mono, R, Headphones
MIDI	In, Out, Thru
Weight	12.5 kg
Keyboard	61 keys with velocity
Polyphony	62 voices
Sound Engine	HI synthesis
ROM	32 MB
Styles	304 styles
Performances	160 performances
Effects	2 stereo digital multi-effect systems
Sequencer	16-track
Inputs	Assignable pedal/switch
Storage	3.5" floppy disk drive
Sequencer Memory	100, 000 notes
Connections	MIDI (In, Out, Thru)
Power Supply	AC adapter (included)
Effects Detail	Reverb (8 types), Chorus (8 types), Delay (8 types)
