FV = FULL VIEW D = Pa80 DISASSEMBLY LD1 = LOWER CASE DISASSEMBLY 1 LD1 = LOWER CASE DISASSEMBLY 2

UD1 = UPPER CASE DISASSEMBLY 1 UD2 = UPPER CASE DISASSEMBLY 2 UD3 = UPPER CASE DISASSEMBLY 3

UD4 = UPPER CASE DISASSEMBLY 4 PSS = POWER SWITCHING SUPPLY MB = MAIN BOARD GROUP

FD = FLOPPY DISK GROUP OB = OUTPUT BOARD

PART LIST HEADPHONE BOARD KIP-2031

CODE PART-TYPE REFERENCE QTY

BOB0005002 EMI FERRITE BLM21B102SPT L1-2 2

CIN0001009 DUAL HEADPH. OP.M5216P U1 1

TRS0001008 NPL BIPOLAR TRASISTOR 2SD2144S Q1-2 2

PART LIST ROTARY ENCODER KIP-2034

CODE PART-TYPE REFERENCE QTY

INT0001006 INCREMENTAL ENCODER RE1 1

PART LIST MAIN FILTER KIP-2038

CODE PART-TYPE REFERENCE QTY

BOB0005001 COIL VK200 2 SPIRE L1-4 4

INT0001012 POWER SWITCH SS-160-7-A SW1 1

PART LIST AFTERTOUCH BOARD KIP-2006

CODE PART-TYPE REFERENCE QTY

CIN0001004 INT.LMC662ACN OP.RAIL TR. U1-B 1

TRX0005001 ORIZ. TRIMMER P5mm 3k3 VR2 1

TRX0005002 ORIZ. TRIMMER P5mm 470k VR1 1

PART LIST WOOD COMPONENTS

CODE PART-TYPE REFERENCE QTY

LEG0001005 DX SPEAKER BOX PANEL LD2 1

LEG0001006 SX SPEAKER BOX PANEL LD2 1

PART LIST METAL COMPONENTS

CODE PART-TYPE REFERENCE QTY

FER0001090 SPEAKER NET UD4 2

FER0001091 F.D.D. SUPPORT FD 1

FER0001092 MAIN BOARD LOWER SHIELD MB 1

FER0001093 MAIN BOARD UPPER SHIELD MB 1

FER0001127 OUTPUT BOARD SUPPORT OB 1

FER0001095 POWER SUPPLY SUPPORT PSS 1

FER0001038 MUSIC REST FV 1

FER0001097 POWER SUPPLY GRID LD1 1

FER0001099 UPPER CASE HOLDER OB 1

FER0001153 KEYBOARD SUPPORT LD1 2
