Korg PA60 Service Manual

FV = FULL VIEW D = Pa80 DISASSEMBLY LD1 = LOWER CASE DISASSEMBLY 1 LD1 = LOWER CASE DISASSEMBLY 2
UD1 = UPPER CASE DISASSEMBLY 1 UD2 = UPPER CASE DISASSEMBLY 2 UD3 = UPPER CASE DISASSEMBLY 3
UD4 = UPPER CASE DISASSEMBLY 4 PSS = POWER SWITCHING SUPPLY MB = MAIN BOARD GROUP
FD = FLOPPY DISK GROUP OB = OUTPUT BOARD
PART LIST DIGITAL AMPLIFIER KIP-2055
CODE PART-TYPE REFERENCE QTY
BOB0001004 BOBINA 10uH LC1-4 4
BOB0005001 EMI SUPP. COIL VK200 L1 1
CIN0002046 SMD 3 ELEM. DUAL CH. GRAPHIC EQ. IC3 1
DIX0005002 SIGNAL DIODE D4 D7 2
DIX0005004 DIODO FAST 1N5819 D1-3 D5 4
DIX0005301 ZENER VOLTAGE REG. DIODE, VZ=4.7V D6 1
FER0001107 DISSIPATORE TO220 X6 1
TRS0001002 TRANSISTOR PNP DIGITALE RN2202 Q3 1
TRS0001010 +8V REG.1A TO220 IC4 1
TRS0001014 STEREO PWM AMPLIFIER IC1 1
TRS0001011 -8V REG. 1A TO220 IC2 1
TRS0005002 PNP TRANSISTOR BC558 Q1-2 2
PART LIST MAIN BOARD KIP-2017
CODE PART-TYPE REFERENCE QTY
BOB0005002 EMI FERRITE BLM21B102SPT L5 L7-18 L26 L28 L32-37 R5-6 R29
R33-34 R38-39 R45 R165
30
BOB0005003 FERRITE DST310-55Y5S223S50 LC1-5 5
BOB0005004 ARRAY IND.BLA3216A102S4 SMD L1-4 L6 L19-25 L27 RA49 14
CIN0002006 I.C. PCM1716E SMD U3 U7 2
CIN0002025 I.C. GM82C765BS-44 (F.D.C) U27 1
CIN0002026 I.C. SN74AHCU04D HEX.UND. U44-45 2
CIN0002027 I.C. TC74HC02AFN QU.2INP U16 1
CIN0002028 I.C. TC74LVX4245FS TRANSCE U13-14 2
CIN0002029 I.C. TC74VHC21FN U46 1
CIN0002030 I.C. SN74AHC32D U43 1
CIN0002031 I.C. SN74AHC374DW U12 1
CIN0002032 I.C. SN74AHCT04D U47 1
CIN0002033 I.C. SN74AHCT139D U48 1
CIN0002034 I.C. SN74AHCT244DW U10-11 U26 U28-29 U40-42 U49 9
CIN0002035 I.C. SN74AHCT245DW U30-31 U38-39 4
CIN0002036 I.C. FSC74LVX32M QUA.2-INP U23 1
CIN0002037 I.C. TGL96 MB87F1710-PFV-S U15 1
CIN0002038 I.C. PCM1800 20bit CONV. U2 1
CIN0002039 I.C. MICRO 32b.XCF5307FT66B U17 1
CIN0002040 I.C. NJM4580M OP.AMP. U4-5 U8-9 4
CIN0003013 I.C. GM76C256CLLFW-55 U32-33 2
CIN0003016 I.C. MX23C6410MC-10 BKOL U37 1
CIN0003017 I.C. MX23C6410MC-10 BKOH U36 1
CIN0003018 I.C. MX23C6410MC-10 BK1L U35 1
CIN0003019 I.C. MX23C6410MC-10 BK1H U34 1
CIN0003020 I.C. MBCG46183-205(MCM99)KORG IT U24 1
CIN0003021 I.C. OTP MX27L512MC-12 U25 1
CIN0003022 NAND FLASH TC58V64AFT U21 1
CIN0003023 I.C. DRAM KM48C512DT-L6(4MX8) U19 1
CIN0003025 IC. SDRAM 64M GM72V661641CT-7J U22 1
CIN0004005 RES. GEN.3,3V ETC811SUC U18 1
QUA0006003 CER. RES. SMD HCM49 6MHz X1 1
QUA0006004 CER. RES. SMD HCM49 16MHz X4 1
QUA0006005 CER. RES. SMD HCM49 24.576MHz X2 1
QUA0006006 CER. RES. SMD HCM49 33MHz X3 1
TRS0002006 REG. +5V 0.5A BA178M05FP U6 1
TRS0002007 REG. +3.3V 0.5A BA033FP U20 1
VTA0001065 SCREWS M2X8 TC Zn Y1-4 4

Korg PA60 Specifications

General

Outputs	L/Mono, R, Headphones
MIDI	In, Out, Thru
Weight	12.5 kg
Keyboard	61 keys with velocity
Polyphony	62 voices
Sound Engine	HI synthesis
ROM	32 MB
Styles	304 styles
Performances	160 performances
Effects	2 stereo digital multi-effect systems
Sequencer	16-track
Inputs	Assignable pedal/switch
Storage	3.5" floppy disk drive
Sequencer Memory	100, 000 notes
Connections	MIDI (In, Out, Thru)
Power Supply	AC adapter (included)
Effects Detail	Reverb (8 types), Chorus (8 types), Delay (8 types)
