Installation
If changes are to be made to the settings, perform the
following steps:
1. Call up online interface of KOSTAL Smart Energy
Meter
Ch. 4.3
2. Call up Modbus configuration under Modbus
settings.
3. Select PIKO IQ/ PLENTICORE from drop-down
list.
Parameter Value
Interface RS485 A
Active slave Yes
Presetting PIKO IQ/PLENTICORE
Slave address 1
Baud rate 38400
Data bits 8
Parity None
Stop bit 2
4. Press “Save” button to accept settings.
H
The inverter has been set up.
INFO
When an inverter is selected, the pre-
defined default values are adopted.
These can be adapted if necessary.
