MAINTENANCE
CRUSHER MAINTENANCE
283
2. Relieve all hydraulic pressure.
3. Lockout/tagout the crusher and any related components. Follow all local lockout/tagout procedures and
regulations.
4. Remove the bowl rotation hoses, bowl clamp hose, and position indicator cable.
NOTE: Pressure will be trapped behind the ball checks if the pressure was not relieved prior to being discon-
nected. This will make reconnecting nearly impossible.
1 Drive Ring
2 Crushing Zone Indicator
1 Position Indicator Cable
2 Bowl Rotation Hoses (not shown)
3 Bowl Rotation Hoses
To Next Page
