REFERENCE INFORMATION
CRUSHER INFORMATION
433
K300+ Medium Fine Chamber
Reduction Ratio: 3:1 to 6:1 max. (Based on no bowl float. If bowl float occurs, then you have gone beyond
the allowable reduction ratio).
See Upper Assembly in parts book for liner hardware.
Item Part Number Chamber Weight
Mantle 456262SX 1843 lbs (836 kg)
Liner 456397SX 1600 lbs (726 kg)
ABC
3 5/8” (92mm) 5 1/8” (130.2mm) 1/2” (12.7mm)
3 3/4” (95.5mm) 5 1/4” (133.3mm) 5/8” (15.9mm)
3 7/8” (98.4mm) 5 3/8” (136.5mm) 3/4” (19mm)
4” (101.6mm) 5 1/2” (139.7mm) 7/8” (22.2mm)
4 1/8” (104.8mm) 5 5/8” (142.9mm) 1” (25.4mm)
Approximate Backing Material
(P/N 090037B Domestic; P/N 090804B International Shipments)
Liner Mantle Chamber
Buckets (22 lb each) 10 3 13
Weight 220 lbs (99.8 kg) 66 lbs (29.9 kg) 286 lbs (129.7 kg)
To Next Page
