Your TP-123EDID XGA / Audio / Data Line Transmitter
4.2 Technical Specifications
1
Table 2
includes the technical specifications of the TP-121EDID
Table 2: Technical Specifications of the TP-121EDID
INPUTS: Video: 1 VGA / UXGA on a 15-pin HD connector
Audio: 1 audio ANALOG 3.5mm mini jack
OUTPUT: 1 RJ-45 OUT connector
BANDWIDTH (-3dB)
2
Audio: 20Hz to 20kHz@0.5dB :
RESOLUTION: Up to WUXGA and 1080p
S/N RATIO: VIDEO: 58dB unweighted, 68.3dB @5MHz weighted
Audio: <-80dB
TOTAL GAIN: Audio: Analog/analog: 0dB; Analog/SPDIF: –12dBFS
COUPLING: AC
TND+N: Audio: <0.01%
POWER SOURCE: 12V DC 60mA
DIMENSIONS: 12.1cm x 7.18cm x 2.42cm (4.76" x 2.83" x 0.95") W, D, H
WEIGHT: 0.3kg (0.67lbs) approx.
ACCESSORIES: Power supply
OPTIONS: 19” rack mount adapter
5 Your TP-123EDID XGA / Audio / Data Line Transmitter
The TP-123EDID is a high-performance transmitter. It accepts a computer
graphics input signal, an unbalanced stereo analog audio signal, unidirectional
(RxD) RS-232 control commands and 12V DC power, over CAT 5 cable, and
transmits to a receiver
3
When the TP-123EDID is connected to a display device and the EDID
CAPTURE button is pressed, the TP-123EDID reads and stores the EDID
(Extended Display Identification Data) from the display device. The display
can be disconnected and later reconnected without rebooting the operating
system.
. The stereo analog audio signal is converted to the
digital audio (S/PDIF) stream before transmitting, thus preserving the quality
of the audio source signals.
The TP-123EDID has a transmission range of more than 300ft (more than
100m) over CAT 5 cabling and can power or be powered by the TP-124
receiver
4
over the same CAT 5 cable and is 12V DC fed.
1 Specifications are subject to change without notice
2 For the Transmitter/Receiver pair
3 For example, the Kramer TP-124 XGA / Audio / Data Line Receiver
4 Download up-to-date Kramer user manuals from our Web site at http://www.kramerelectronics.com
