Kramer VP-475UX User Manual

Kramer Electronics Ltd.
VP-475UX – Protocol 3000
27
Function
Description
Syntax
Parameters/Attributes
Example
VID-RES?
Get output resolution.
“Get” command
with is_native=ON
returns native
resolution VIC, with
is_native=OFF returns
current resolution.
To use “custom
resolutions” (entries
100-105 In View
Modes), define them
using the DEF-RES
command.
COMMAND
#VID-RES?io_mode,io_index,is_native<CR>
FEEDBACK
~nn@VID-RES?io_mode,io_index,is_native,resolution<CR><LF>
io_mode –
1 – Output
io_index – Number that indicates the
specific input or output port:
1-N (N= the total number of input or
output ports)
is_native – Native resolution flag
0 – Off
1 – On
resolution – Resolution index
0=No Signal (for input) / Native - EDID
(for output)
1=640x480p@59.94Hz/60Hz
2=720x480p@59.94Hz/60Hz
3=720x480p@59.94Hz/60Hz
4=1280x720p@59.94Hz/60Hz
16=1920x1080p@59.94Hz/60Hz
17=720x576p@50Hz
18=720x576p@50Hz
19=1280x720p@50Hz
31=1920x1080p@50Hz
32=1920x1080p@23.97Hz/24Hz
33=1920x1080p@25Hz
34=1920x1080p@29.97Hz/30Hz
65=800x600p@60Hz
66=1024x768@60Hz
67=1280x768p@60Hz
68=1280x1024p@60Hz
69=1600x1200p@60Hz
70=1680x1050p@60Hz
71=1920x1200@60Hz
72=3840x2160p@24Hz
73=3840x2160p@25Hz
74=3840x2160p@30Hz
75=3840x2160p@50Hz
Set output resolution:
#VID-RES?1,1,1<CR>
W-SATURATION
Set image saturation
per output.
Value limits can
vary for different
devices.
Value is a property of
input connected to
current output.
Changing input source
might cause changes
in this value (refer
device definitions).
In devices that enable
showing multiple
outputs on one display
– each in a separate
window – this
command relates only
to the window
associated with the
output indicated in the
out-index parameter.
COMMAND
#W-SATURATIONout_index,value<CR>
FEEDBACK
~nn@W-SATURATIONout_index,value<CR><LF>
out_index – Number that indicates the
specific output:
1-N (N= the total number of outputs)
value – Saturation value (0-100)
Set saturation for output 1 to
50:
#W-SATURATION1,50<CR>
W-SATURATION?
Get image saturation
per output.
Value limits can
vary for different
devices.
Value is a property of
input connected to
current output.
Changing input source
might cause changes
in this value (refer
device definitions).
In devices that enable
showing multiple
outputs on one display
– each in a separate
window – this
command relates only
to the window
associated with the
output indicated in the
out-index parameter.
COMMAND
#W-SATURATION?out_index<CR>
FEEDBACK
~nn@W-SATURATIONout_index,value<CR><LF>
out_index – Number that indicates the
specific output:
1-N (N= the total number of outputs)
value – Saturation value (0-100)
Get saturation for output 1:
#W-SATURATION?1<CR>
