Kramer VP-551X

Kramer Electronics Ltd.
VP-551X – Using the Embedded Webpages
36
To set the input audio source:
1. In the Navigation pane, click Audio Settings. The Audio Settings page appears (see
Figure 27).
2. For each HDMI input, select the audio source (Automatic, Analog or Embedded) from
the drop-down box.
The input source is selected.
Adjusting Microphone Settings
To adjust microphone settings:
1. In the Navigation pane, click Audio Settings. The Audio Settings page appears (see
Figure 27).
2. Under Mic Settings you can do the following:
▪ Open the Mic Mode drop-down box and select the microphone mode.
▪ Select Mic1, Mic2 or Both.
3. When Mic mode is set to Talkover, set the Depth, Trigger, Attack time, Hold time and
Release time by:
▪ Entering the value in the text box next to the input name.
▪ Sliding the volume switch.
For further details, see Talkover Mode on page 15.
Configuring Additional Audio Settings
You can configure other audio parameters under the Settings area.
To configure additional audio settings:
1. In the Navigation pane, click Audio Settings. The Audio Settings page appears.
2. Under Settings you can do the following:
▪ Set DRC (Dynamic Range Compression) to On or Off (default).
▪ Adjust the Bass and Treble by:
 Entering the value in the text box next to the input name.
 Sliding the volume switch.
 Set Loudness to On or Off (default).
▪ Apply DSP (default) to the embedded audio or Bypass it.
