Kramer Electronics Ltd.
VP-551X – Protocol 3000
58
Function
Description
Syntax
Parameters/Attributes
Example
FACTORY
Reset device to factory
default configuration.
This command
deletes all user data from
the device. The deletion
can take some time.
Your device may require
powering off and
powering on for the
changes to take effect.
COMMAND
#FACTORY<CR>
FEEDBACK
~nn@FACTORYOK<CR><LF>
Reset the device to factory
default configuration:
#FACTORY<CR>
FAN?
Get fan status.
COMMAND
#FAN?<CR>
FEEDBACK
~nn@FAN?status<CR><LF>
status –
0 = Fail
1 = Pass
Get fan status:
#FAN?<CR>
HDCP-MOD
Set HDCP mode.
Set HDCP working
mode on the device input:
HDCP supported -
HDCP_ON [default].
HDCP not supported -
HDCP OFF.
HDCP support changes
following detected sink -
MIRROR OUTPUT.
When you define 3 as the
mode, the HDCP status is
defined according to the
connected output in the
following priority: OUT 1,
OUT 2. If the connected
display on OUT 2
supports HDCP, but OUT
1 does not, then HDCP is
defined as not supported.
If OUT 1 is not
connected, then HDCP is
defined by OUT 2.
COMMAND
#HDCP-MOD stage,inp_id,mode<CR>
FEEDBACK
~nn@HDCP-MOD stage,inp_id,mode<CR><LF>
stage – Input/Output
0 = Input
1 = Output
inp_id – Input number:
1 = HDMI 1
2 = HDMI 2
3 = HDMI 3
4 = HDMI 4
5 = HDMI 5
6 = HDMI 6
7 = HDMI 7
8 = HDMI 8
Output number
1 = HDMI
2 = HDBT
mode – HDCP mode
Input:
0 = Off
1 = On
Output:
2 = Follow input
3 = Follow output
Set the input HDCP-MODE of
input HDMI 1 to Off:
#HDCP-MOD 0,1,0<CR>
HDCP-MOD?
Get HDCP mode.
Set HDCP working
mode on the device input:
HDCP supported -
HDCP_ON [default].
HDCP not supported -
HDCP OFF.
HDCP support changes
following detected sink -
MIRROR OUTPUT.
COMMAND
#HDCP-MOD? stage,inp_id<CR>
FEEDBACK
~nn@HDCP-MOD stage,inp_id,mode<CR><LF>
stage – Input/Output
0 = Input
1 = Output
inp_id – Input number:
1 = HDMI 1
2 = HDMI 2
3 = HDMI 3
4 = HDMI 4
5 = HDMI 5
6 = HDMI 6
7 = HDMI 7
8 = HDMI 8
Output number
1 = HDMI
2 = HDBT
mode – HDCP mode
Input:
0 = Off
1 = On
Output:
2 = Follow input
3 = Follow output
Get the input HDCP-MODE of
input HDMI 1:
#HDCP-MOD? 0,1<CR>
HELP
Get command list or help
for specific command.
COMMAND
#HELP<CR>
#HELPcommand_name<CR>
FEEDBACK
1. Multi-line:
~nn@Devicecommand,command…<CR><LF>
To get help for command use: HELP (COMMAND_NAME)<CR><LF>
~nn@HELPcommand:<CR><LF>
description<CR><LF>
USAGE:usage<CR><LF>
command – Name of a specific
command
Get the command list:
#HELP<CR>
To get help for
AV-SW-TIMEOUT:
HELPAV-SW-TIMEOUT<CR>
IMAGE-PROP
Set the image size.
Sets the image
properties of the selected
scaler.
COMMAND
#IMAGE-PROP scaler,status<CR>
FEEDBACK
~nn@IMAGE-PROP P1 ,P2…<CR><LF>
scaler = 1
status – Status
0 = Over scan
1 = Full
2 = Best fit
3 = Pan scan
4 = Letter box
5 = Under 2
6 = Under 1
7 = Follow in
Set the image size to Full:
#IMAGE-PROP 1,1<CR>
