6 Connecting the VS-44H 4 x 4 HDMI Matrix Switcher
To connect the VS-44H, as the example in Figure 2 illustrates, do the
following
1
1. Connect up to four HDMI sources
:
2
2. Connect the OUT HDMI connectors to up to four HDMI acceptors
(for example, DVD players) to the
IN HDMI connectors.
3
3. If required, connect a PC and/or controller to the RS-232 port (see
section
(for example, LCD displays with built-in speakers).
7.5) and/or the ETHERNET port (see section 7.6).
4. Connect the power cord (not shown in
Figure 2).
5. If required, acquire the EDID (see section
7.1).
1 Switch OFF the power on each device before connecting it to your VS-44H. After connecting your VS-44H, switch on its
power and then switch on the power on each device
2 You do not have to connect all the HDMI sources
3 You do not have to connect all outputs
