Krautkramer DM4 DL Operating Manual

DM4E, DM4, DM4 DL Operating Manual Page 25
5.0 Specifications
Nominal Contact Measurement Temp.
Model Probe Description Frequency Diameter Range (Steel) Range
DP-104 High Penetration 1 MHz 1.25" .200" min <130°F
31.8 mm 5.0 mm min <54°C
DA301 General Purpose 5 MHz .475" .0 6 0" to 8.0" <130°F
12.1 mm 1.5 to 200 mm <54°C
DA303 High Penetration 2 MHz .635" .200" min <130°F
16.2 mm 5.0 mm min <54°C
DA312 Thin Materials 10 MHz .30" .025" to 1.0" <130°F
7.6mm .6 to 25 mm <54°C
DA312B16 * Small Footprint 10 MHz .120” .025 to .5” <130°F
3 mm .63 to 12.7mm <54°C
KB550BTH * Boiler Tube 5 MHz .375" .060" to 2.0" <130°F
9.5 mm 1.5 to 50 mm <54°C
KB550FH * Fingertip 5 MHz .375" . 06 0" to 2.0" <130°F
9.5 mm 1.5 to 50 mm <54°C
FH2E-WR High Sensitivity Fingertip 8 MHz .550” .0 3 0" to 2.0" <130°F
Wear Resistant 14.0 mm .75 to 50 mm <54°C
KBA560-WR General Purpose 5 MHz .700" .0 60" to 8.0" <450°F
Wear Resistant 17.8 mm 1.5 to 200 mm <230°C
KBA525 Small Footprint 10 MHz .200” .025” to 1.0” <130°F
5 mm .63 to 25.4 mm <54°C
NOTE: Probe specifications are subject to change without notice.
5.3 Dual Multi “Through Coating” Mode Probe Specifications
Nominal Contact Through Coating Temp.
Model Description Frequency Diameter Measurement Range Range
KBA560-D Dialog-General Purpose 5 MHz .625” .120” to .800” <250°F
15.9mm 3 to 20 mm <121°C
KBA560 General Purpose 5 MHz .625” .120” to .800” <450°F
15.9mm 3 to 20 mm <230°C
KBA560-WR General Purpose 5 MHz .700” .120” to .800” <450°F
Wear Resistant 17.8mm 3 to 20mm <230° C
DA312 Thin Materials 10 MHz .30 ” .080” to .50” <130°F
7.6mm 2 to 13 mm < 54°C
DA301/DA311 General Purpose 5 MHz .475” .120” to .800” <130°F
12.1mm 3 to 20 mm < 54°C
NOTE: Actual “Through Coating” measurement will vary depending upon the
type and thickness of the coating, the thickness of the metal and the quality
of the metal and the quality of the bind between the coating and the metal.
Probe specifications are subject to change without notice.
DM401-GP General Purpose 5 MHz .700” .120” to .800” <300°F
17.8mm 3 to 20 mm <150°C
NOTE: The Auto Mode Linearity for the DA301 probe is ± 0.005 inch (± 0.13 mm)
