Kreg ADAPTIVE CUTTING SYSTEM - Using the Saw: Bevel Overrides

USING THE SAW
Bevel Overrides
Fittingtwopartstogetherwhentheedge
ofonepartisnotsquarerequirescuttinga
slightcompensatingbevelonthesecond
part. When the needed bevel adjustment
fallsbelowthe0°markonthebevelscale,
usethe-1°override.Insimilarfashion,
compensate for a miscut bevel on one part
ofamiterjointbyusingthe+47°override.
Both procedures are shown below.
-1° Override
(1)Loosenthebevellocks.
(2) Bevel saw to approximately 30º to access
the override locks
(3)Turnboth-1°overridelockstothe
 -1°position.
1
3
3
2
1
3
ATTENTION
!
Always return both override locks to the 0°
position after making your cut.
Toreturntothe0-45°bevelrange,loosen
thebevellocks,turnthe-1°overridelocksto
the0°position,tiltthesawdown,andtighten
the bevel locks.
(4)Bevelsawdownto-1º.
(5)Tightenthebevellocks.
4
4
5
5
