Kreg ADAPTIVE CUTTING SYSTEM - Setup: Toe-In Adjustment

SETUP
ATTENTION
!
For smooth cuts, the face of the saw blade must
be parallel to the edges of the saw base. This alignment is made at the
factory and user adjustment, shown below, should only be necessary
in rare circumstances, such as signicant impact to the saw base.
Toe-In Adjustment
(2) Insert a business card or construction
paper approximately 0.010" thick between
 abladetoothandtheanti-chipstripatthe
 rearoftheblade.Ifthegapissmallerthan
0.010" no calibration is needed.
(1)Plungethesawtotheblade-change
 position.(SeeChangingthebladeinthe
 followingsection.)Verifythesaw-blade
 toothcontactstheanti-chipstripatthe
front of the blade.
2
1
If there is a gap then proceed to step 3.
If the gap is larger than 0.010" thick proceed to step 3.
