Kreg ADAPTIVE CUTTING SYSTEM - Page 22

GUIDE TRACK COMPONENTS
(3)Turntheguidetrackupsidedown
and slide a second track connector
 intotheT-slot.
(4)Threadinandtightenthesetscrews.
(8)Turntheguidetracksrightsideupand
 aligntheedgeswithastraightedge.
(9)Threadinandtightenthesetscrews.
3
4
4
ATTENTION
!
Stagger the ends of the guide track
connectors for easier insertion into the second guide track.
(5)Slidethesecondguidetrackontothe
 protrudingtrackconnectors.
(6)Alignthetrackwithastraightedge.
(7)Threadinandtightenthesetscrews.
7
5
6
7
9
8
9
StaggerEnds
